50 Hz. DURA-JET
Sta-Rite Pool/Spa Group
293 Wright Street, Delavan, WI 53115
North America: 800-752-0183, FAX 800-582-2217
International: 262-728-5551, FAX: 262-728-4461, TELEX: ITT 4970245
www.sta-ritepool.com
Union City, TN • Delavan, WI • Mississauga, Ont. • Murrieta, CA
Printed in U.S.A. ©2003, Sta-Rite Industries, Inc.
5DJ Series
O
W
N
E
R '
INSTALLATION, OPERATION & PARTS
SPA PUMP
TM
S
M
A
N
U
This manual should be furnished to
the end user of this pump; its use
will reduce service calls, chance of
injury, and will lengthen pump life.
A
L
SX377 (3/7/03)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pentair STA-RITE DURA-JET 5DJ Series
Summary of Contents for Pentair STA-RITE DURA-JET 5DJ Series
- Page 1 50 Hz. DURA-JET SPA PUMP 5DJ Series R ’ INSTALLATION, OPERATION & PARTS This manual should be furnished to the end user of this pump; its use will reduce service calls, chance of injury, and will lengthen pump life. Sta-Rite Pool/Spa Group 293 Wright Street, Delavan, WI 53115 North America: 800-752-0183, FAX 800-582-2217 International: 262-728-5551, FAX: 262-728-4461, TELEX: ITT 4970245...
-
Page 2: Important Safety Instructions
DURA-JET SPA PUMP To avoid unneeded service calls, prevent possible injuries, and get the most out of your pump, READ THIS MANUAL CAREFULLY! The Sta-Rite ‘5DJ’ Series Spa Pump: • Is designed to circulate hot water in spas and hot tubs. •... -
Page 3: Installation
INSTALLATION Spa Fittings: Size and number of jets will have a major effect on jet Installation and wiring of pump should only be done by action. qualified, licensed personnel. Typical installations use up to four 7/8" or 3/4" diameter Pump mount must: jets or up to seven 1/2"... - Page 4 Wiring: Left Side Right Side See the wiring diagram on the motor housing for wiring connection information. Pump must be permanently con- Black Black Motor nected to circuit. Line Install a Ground Fault Circuit Interrupter (GFCI) in circuit; Brown it will sense a short-circuit to ground and disconnect Blue power before it becomes dangerous to pool users.
-
Page 5: Operation
OPERATION Do not block pump suction! To do so with body may cause severe or fatal injury. Small children using spa must ALWAYS have close adult supervision! • Tub should have dual suction outlets to prevent body or hair entrapment. •... -
Page 6: Pump Service
PUMP SERVICE Hazardous voltage. Can shock, burn,or cause death. Disconnect power before working on pump or motor. Pump should only be serviced by qualified personnel. To avoid dangerous or fatal electrical shock haz- Figure 5 ard, disconnect power to motor before working on pump or motor! 7. -
Page 7: Draining Pump
STORAGE/ 1. Close all valves on suction and return piping. WINTERIZING 2. Remove drain plug in bottom of front plate. 3. Drain all piping and storage tanks exposed to freezing To prevent damage to components from temperatures. fumes, store spa chemicals away from pump and spa. If possible, store chemicals in another room. -
Page 8: Troubleshooting Guide
TROUBLESHOOTING GUIDE Read and understand safety and operating instructions in this manual before doing any work on pump! A. PUMP DOES NOT OPERATE 1. Check GFCI for proper operation according to GFCI manufacturer’s instructions. 2. Check for plugged impeller. Follow disassembly/as- sembly instructions under “Pump Service”, Page 9.
