INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with questions regarding installation, operation or service.
NOTICE: DO NOT discard this manual!
Artisan
Series
Models:
This appliance may be installed in an after-
market, permanently located, manufactured
(mobile) home, where not prohibited by local
codes.
This appliance is only for use with the type of
gas indicated on the rating plate. This appli-
ance is not convertible for use with other
gases.
Owner's Manual
Care and Operation
Monessen • AVFL Series Owner's Manual • 4099-900 Rev. C • 06/21
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
• DO NOT store or use gasoline or other flam-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Leave the building immediately.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas sup-
plier's instructions.
- If you cannot reach your gas supplier, call
the fire department.
• Installation and service must be performed
by a qualified installer, service agency, or the
gas supplier.
In the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas fitter.
See appliance installation manual for additional
Commonwealth of Massachusetts requirements.
• DO NOT install this appliance in a bedroom
or bathroom. Please refer to page 6 Sec-
tion F of the Installation Manual for proper
appliance placement.
This is an unvented gas-fired heater. It uses air
(oxygen) from the room in which it is installed.
Provisions for adequate combustion and ven-
tilation air must be provided. Refer to page 6
of the Installation Manual.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Artisan AVFL Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Monessen Hearth Artisan AVFL Series

Summary of Contents for Monessen Hearth Artisan AVFL Series

  • Page 1 Owner’s Manual Care and Operation INSTALLER: Leave this manual with party responsible for use and operation. OWNER: Retain this manual for future reference. Contact your dealer with questions regarding installation, operation or service. NOTICE: DO NOT discard this manual! WARNING: FIRE OR EXPLOSION HAZARD Artisan Failure to follow safety warnings exactly...

  • Page 2: Table Of Contents

    Safety Alert Key: • DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury. • CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. •...

  • Page 3: Welcome

    Welcome Read this manual before operating this appliance. Please retain this Owner’s Manual for future reference. Read the Installation Manual before making any installation or finishing changes. A. Congratulations This owner’s manual should be retained for future reference. We suggest that you keep it with your other Congratulations and thank you for selecting a Monessen important documents and product manuals.

  • Page 4: Limited Lifetime Warranty

    B. Limited Lifetime Warranty Hearth & Home Technologies LLC LIMITED LIFETIME WARRANTY Hearth & Home Technologies LLC (“HHT”) extends the following warranty for HHT gas, wood, pellet and electric hearth appliances (each a “Product” and collectively, the “Product(s)”) and certain component parts set forth in the table below (“Component Part(s)”) that are purchased from a HHT authorized dealer or distributor.
  • Page 5 B. Limited Lifetime Warranty (continued) WARRANTY CONDITIONS: • Because HHT cannot control the quality of any Products sold by unauthorized sellers, this Warranty only covers Products that are purchased through an HHT authorized dealer or distributor unless otherwise prohibited by law; a list of HHT authorized dealers is available on the HHT branded websites.

  • Page 6: Product Specific Information

    Product Specific Information A. Appliance Certification B. BTU Specifications Models Maximum Minimum Orifice MODEL: AVFL42NIP-BU, AVFL42PIP-BU, AVFL42NIP-RB, Input Input BTU/h Size (DMS) BTU/h AVFL42PIP-RB, AVFL48NIP, AVFL48PIP, AVFLST48NIP, AVFL42NIP-BU (NG) 34,000 23,500 .1110(#34) (0-2000 FT) AVFLST48PIP,AVFL60NIP-B, AVFL60PIP-B LABORATORY: UNDERWRITERS LABORATORIES, INC. AVFL42PIP-BU (PROPANE) 33,000 26,000...

  • Page 7: Important Safety And Operating Information

    Important Safety and Operating Information A. Appliance Safety Clear Space WARNING! DO NOT place combustible objects in front WARNING! DO NOT operate appliance before read- of the appliance. High temperatures may start a fire. See ing and understanding operating instructions. Failure Figure 3.1.
  • Page 8 Important Safety and Operating Information (continued) OWNER Please retain these instructions for future reference. WARNING • Any change to this appliance or its controls can be dangerous. • Improper installation or use of the appliance can cause serious injury or death from fire, burns, explosion or carbon monoxide poisoning.

  • Page 9: General Operating Parts

    B. General Operating Parts 18. Input ratings are shown in BTU per hour and are for elevations up to 2,000 feet. For elevations above 2,000 Figure 3.2 references the general operating parts of the feet, input ratings should be reduced 4 percent for each appliance and the section of this manual in which they are 1,000 feet above sea level.

  • Page 10: Good Faith Wall Surface/Tv Guidelines

    D. Good Faith Wall Surface TV Guidelines (AVFL42N(P)IP-BU, AVFL48N(P)IP, AVFL60N(P)IP-B, AND AVFLST48N(P)IP appliances) Good Faith Guidelines for TV on’s above a Typical Gas Fireplace Combus ble Mantel inch 22.00 Non-Combus ble Mantel inch 20.00 TV recessed into the wall TV on the wall 6"...
  • Page 11 Good Faith Wall Surface TV Guidelines (continued) (AVFL42N(P)IP-RB) Good Faith Guidelines for TV on’s above a Typical Gas Fireplace Combus ble Mantel inch 14.00 Non-Combus ble Mantel inch 12.00 TV recessed into the wall TV on the wall 6" Min. "...

  • Page 12: Before Lighting Appliance

    E. Before Lighting Appliance Before operating this appliance for the first time, have a qualified service technician: • Verify all shipping materials have been removed from inside and/or underneath the firebox. • Review proper placement of crushed glass media. • Ensure that there are no gas leaks. •...

  • Page 13: Lighting Instructions (Ipi)

    F. Lighting Instructions (IPI) FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fi re or explosion may result causing property damage, personal injury or loss of life. • Immediately call your gas supplier from a neighbor’s phone. Follow the gas sup- A.

  • Page 14: Initial Use

    Wall Switch: G. Initial Use • Toggle the switch as you would under normal Initial Break-in Procedure circumstances. • The appliance should run three to four hours continuously Wireless Remote: on high. • Remote receiver is integrated into the ignition module •...
  • Page 15 IntelliFire Plus™ Remote Control RC300 IntelliFire Plus™ Multifunction Remote Control Installation & Operating Instructions FCC Requirements Hearth & Home Technologies disclaims any responsibility WARNING! Risk of Fire! Changes or modifications to for, and the warranty will be voided by, the following actions: this unit not expressly approved by the party responsible •...
  • Page 16 Installation of Remote Control Housing CAUTION! Risk of Fire! DO NOT install damaged or modified components Warranty will be voided if damaged or modified components are installed. Kit components: One remote control, two #6 screws, two wall anchors and 3 AAA batteries. If batteries are properly installed the remote will turn on 1.
  • Page 17 Display Screen Idle When Remote is in ON Mode The remote control will go into an idle mode if no but- THERMOSTAT DESIRED tons are pressed within 5 seconds. Press any button to APPLIANCE STATUS TEMP SETTING resume full functionality. In idle mode, only active func- tions will show on the screen.
  • Page 18 About ON Mode NOTICE: If your installation includes an optional wired ON/OFF wall switch, it should be in the OFF position when • All functions can be accessed when the remote control using the RC300 in thermostat mode. is in the ON mode. Adjusting Timer •...
  • Page 19 Manual Appliance Shutoff Appliance On/Off Switch In the unlikely event that the remote wall switch malfunc- On/Hi/Med/Lo/ tions and will not turn off the appliance, call your dealer for service assistance. In the meantime, you may choose one of the following actions to turn off the appliance: CAUTION! Risk of burns! Appliance surfaces are hot when operating and during cool down.
  • Page 20 Frequently Asked Questions/Troubleshooting Symptom Possible Cause Corrective Action Batteries Verify batteries are functional and installed correctly. Remote control is in Child Disengage Child Lock mode. Remote control will not transmit Lock mode Buttons not being pressed Press button firmly for one to two seconds to ensure transmis- firmly sion to module.

  • Page 21: Maintenance And Service

    Maintenance and Service Surrounds Any safety screen or guard removed for servicing must be replaced prior to operating the appliance. Frequency: Annually When properly maintained, your appliance will give you By: Homeowner many years of trouble-free service. Contact your dealer Tools needed: Protective gloves, stable work surface to answer questions regarding proper operation, trouble- •...
  • Page 22 Firebox Burner Ignition and Operation Frequency: Annually Frequency: Annually By: Qualified Service Technician By: Qualified Service Technician Tools needed: Protective gloves, vacuum cleaner, whisk Tools needed: Protective gloves, sandpaper, steel wool, broom, flashlight, voltmeter, indexed drill bit set, and a cloths, mineral spirits, primer and touch-up paint.

  • Page 23: Frequently Asked Questions And Troubleshooting

    Frequently Asked Questions and Troubleshooting A. Frequently Asked Questions ISSUE SOLUTION When first operated, this appliance may release an odor for the first several hours. This is caused by the burning off of any oils remaining from manufacturing or from finishing materials or adhesives used around the appliance during installation.
  • Page 24 IntelliFire Plus™ ODS Ignition System (Continued) Verify that incoming gas line ball valve is “open”. Verify Gas supply. that inlet pressure reading is within acceptable limits. Verify gap of igniter to right side of pilot hood. The gap Igniter gap is too large. should be approximately .17 in.

  • Page 25: Troubleshooting-Screen/Leds/Control Panel

    C. Troubleshooting – Screen/LEDs/Control Panel SYMPTOM POSSIBLE CAUSE CORRECTIVE ACTION Check that GFCI breaker is operating as intended and is not tripped. Verify that AC power has been connected to No AC power to ap- the appliance. Ensure that both the 4V IPI control module pliance power supply as well as the LED power supply are securely plugged into the appliance junction box.

  • Page 26: Reference Materials

    Reference Materials A. Accessories Install approved accessories per instructions included with accessories. Contact your dealer for a list of approved acces- sories. WARNING! Risk of Fire and Electric Shock! Use ONLY Hearth & Home Technologies-approved optional accessories with this appliance. Using non-listed accessories could result in a safety hazard and will void the warranty. •...

  • Page 27: Service Parts

    ► B. Service Parts ARTISAN Service Parts Beginning Manufacturing Date: April 2021 Ending Manufacturing Date: Active 42” Artisan Vent Free Linear Fireplace AVFL42NIP-BU AVFL42NIP-RB AVFL42PIP-BU AVFL42PIP-RB 11.13 11.12 11.11 11.1 11.2 11.9 11.10 11.3 11.4 11.5 11.6 11.7 11.8 Part number list on following page. 06/21 Monessen •...
  • Page 28 ARTISAN Service Parts Beginning Manufacturing Date: April 2021 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Stocked Home Technologies does not sell directly to consumers. Provide model number and serial number when requesting service parts from your dealer or distributor.
  • Page 29 AVFL48NIP, AVFL48PIP Service Parts Beginning Manufacturing Date: April 2021 48” Artisan Vent Free Linear Fireplace Ending Manufacturing Date: Active 10.14 10.13 10.12 10.11 10.1 10.2 10.10 10.3 10.4 10.9 10.5 10.6 10.7 10.8 Part number list on following page. 06/21 Monessen •...
  • Page 30 AVFL48NIP, AVFL48PIP Service Parts Beginning Manufacturing Date: April 2021 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Stocked Home Technologies does not sell directly to consumers. Provide model number and serial number when requesting service parts from your dealer or distributor.
  • Page 31 AVFL48NIP, AVFL48PIP Service Parts Beginning Manufacturing Date: April 2021 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Stocked Home Technologies does not sell directly to consumers. Provide model number and serial number when requesting service parts from your dealer or distributor.
  • Page 32 AVFLST48NIP, AVFLST48PIP Service Parts Beginning Manufacturing Date: April 2021 Ending Manufacturing Date: Active 48” See-Through Artisan Vent Free Linear Fireplace 9.14 9.13 9.12 9.11 9.10 Part number list on following page. 06/21 Monessen • AVFL Series Owner’s Manual • 4099-900 Rev. C • 06/21...
  • Page 33 AVFLST48NIP, AVFLST48PIP Service Parts Beginning Manufacturing Date: April 2021 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Stocked Home Technologies does not sell directly to consumers. Provide model number and serial number when requesting service parts from your dealer or distributor.
  • Page 34 AVFLST48NIP, AVFLST48PIP Service Parts Beginning Manufacturing Date: April 2021 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Stocked Home Technologies does not sell directly to consumers. Provide model number and serial number when requesting service parts from your dealer or distributor.
  • Page 35 AVFL60NIP-B, AVFL60PIP-B Service Parts Beginning Manufacturing Date: April 2021 Ending Manufacturing Date: Active 60” Artisan Vent Free Linear Fireplace 10.14 10.13 10.12 10.11 10.1 10.2 10.10 10.3 10.4 10.9 10.5 10.6 10.7 10.8 Part number list on following page. 06/21 Monessen •...
  • Page 36 AVFL60NIP-B, AVFL60PIP-B Service Parts Beginning Manufacturing Date: April 2021 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Stocked Home Technologies does not sell directly to consumers. Provide model number and serial number when requesting service parts from your dealer or distributor.
  • Page 37 AVFL60NIP-B, AVFL60PIP-B Service Parts Beginning Manufacturing Date: April 2021 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Stocked Home Technologies does not sell directly to consumers. Provide model number and serial number when requesting service parts from your dealer or distributor.

  • Page 38: Massachusetts Residents Only

    C. MASSACHUSETTS RESIDENTS ONLY Please read and follow these special requirements NOTE REGARDING VENTED PRODUCTS 2. Approved Carbon Monoxide Detectors. Each carbon This product must be installed by a licensed plumber or monoxide detector as required in accordance with the above gas fitter when installed within the Commonwealth of provisions shall comply with NFPA 720 and be ANSI/UL 2034 Massachusetts.

  • Page 39: Contact Information

    D. Contact Information Monessen, a brand of Hearth & Home Technologies 7571 215 Street West, Lakeville, MN 55044 www.monessenhearth.com Please contact your dealer with any questions or concerns. For the location of your nearest dealer, please visit www.monessenhearth.com - NOTES - ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________...
