- Page 1 ® Welch Allyn 767 SureTemp 4™ Thermometer System Directions For Use...
- Page 2 © 1995 by Diatek Instruments, Inc., A Welch Allyn Company. All rights reserved. No part of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopy, without prior consent in writing from Diatek.
- Page 3 Thank you for purchasing the Welch Allyn 767 SureTemp 4™ thermometer. The operating and maintenance instructions found in this manual should be followed to ensure years of accurate and reliable service. Please read these instructions thoroughly before using your 767 SureTemp 4™ thermometer.
-
Page 4: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ................... 1 SAFETY & WARNINGS ................. 2 PARTS ....................3 MOUNTING INSTRUCTIONS ............... 4 SETUP ....................8 CHANGING PROBES ..............8 FEATURES .................... 9 OPERATION ..................12 TAKING ORAL TEMPERATURES ..........13 TAKING RECTAL TEMPERATURES ........... 15 USING MONITOR MODE ............ -
Page 5: Introduction
INTRODUCTION The Welch Allyn 767 SureTemp 4™ is a wall mounted thermistor thermometer to be used for measuring patient temperatures ranging from 84 °F to 108 °F (28.9 °C to 42.2 °C). Oral and rectal probes utilize single-use dis- posable probe covers which limit cross-contamination. - Page 6 Do not use the thermometer if you notice any signs of damage to the probe or instrument. Contact our Customer Service Department for immediate assistance. • Do not ETO sterilize without using proper procedures described in the 767 SureTemp 4 technical manual.
-
Page 7: Parts
Display Probe storage channel Dual probe cover storage well Probe connector receptacle Probe connector receptacle latch Probe Probe handle collar Ejection button Mode selection button Figure 1... -
Page 8: Mounting Instructions
MOUNTING INSTRUCTIONS Existing 76710 or 76720 installation: Unplug the 767 wall transformer from the wall outlet. Remove the 76710 or 76720 wall transformer from its mounting plate by pushing upwards on the unit and pulling it away from the wall mounting plate. BACKPLATE TO POWER... - Page 9 Fasten the 767 SureTemp 4 thermometer to the 76710 or 76720 wall transformer as follows: Align the thermometer attachment plate within the groove on the back of the main unit. Line up the electrical contact blades with the corresponding blade openings on the main housings.
- Page 10 Follow the Mounting Instructions found in the 767 Diagnos- tic System owner’s manual to attach the mounting plate to the wall. Fasten the 767 SureTemp 4 thermometer to the 76710 or 76720 wall transformer as follows: Align the thermometer attachment plate within the groove on the back of the main unit.
- Page 11 767 SURETEMP 4 MODULE MAIN UNIT CONNECTION BLADES Slide the 767 SureTemp 4 thermometer into the main unit until the gap between the devices is closed. Secure the thermometer in place, as shown using the two Philips head screws provided.
-
Page 12: Setup
SETUP Install supplied Oral probe or optional Rectal probe by inserting the latching plug on the end of the coiled cord into plug receptacle on the unit. The plug snaps into place and cannot be removed without depressing the latch. (Figure 1). Insert probe shaft completely into probe storage channel. -
Page 13: Features
FEATURES & DISPLAY INDICATORS • Normal Mode: The thermometer takes oral temperatures in about 4 seconds and rectal temperatures in about 15 seconds. The unit will always operate in Normal mode unless the Mode button is depressed for more than 2 seconds (with probe removed from the channel) which changes it to Monitor Mode. - Page 14 Mode Table Step 2 Feature Step 1 Toggle Between While temperature is Press Mode °F or °C Setting displayed, with probe in button. Release or out of storage channel within 2 seconds Monitor Mode Remove probe from Press Mode storage channel button for more than 2 seconds Temperature...
- Page 15 Displayed when an oral probe is installed. When displayed, the thermometer is characterizing the probe. will blink while will remain on. Wait for the display to clear before taking a temperature. Oral Probe: This icon is displayed to show that an oral probe has been selected.
-
Page 16: Operation
Error Codes: If an error code is displayed, refer to the troubleshooting section of your technical manual or contact the Diatek Customer Service Department. Will display if the oral probe characterization process exceeds 70 seconds. Thermometer will automati- cally restart the characterization process. Display Test: All segments of the thermometer display will appear briefly when the probe is removed... -
Page 17: Taking Oral Temperatures
Press collar down firmly to secure the cover. TAKING ORAL TEMPERATURES - BLUE CAPPED PROBE The ability of the 767 SureTemp 4™ to take an accurate temperature in 4 seconds requires correct user technique. 1. Insert the probe tip gently SUBLINGUAL POCKETS into the patient’s slightly... - Page 18 3. During the temperature measurement cycle, “walking” segments will appear on the display in- dicating measurement is in process. 4. When the final temperature has been reached, a tone will sound and the patient’s temperature will be displayed. 5. After the temperature measurement is com- plete, remove the probe from the patient, then...
-
Page 19: Taking Rectal Temperatures
TAKING RECTAL TEMPERATURES - RED CAPPED PROBE 1. Exchange the oral probe (blue ejection button) for the rectal probe (red ejection button) by removing the probe from the storage channel, unplugging the probe connector from the thermometer, and repeating steps 1 through 6 in the SETUP section. -
Page 20: Using Monitor Mode
4. When the final tempera- ture is reached, a tone will sound and the tem- perature will be dis- played. Rectal tempera- ture measurements will take about 15 seconds. 5. After the temperature measurement is complete, remove the probe from the patient, then eject the probe cover by firmly pressing the ejection button on the probe. -
Page 21: Taking Axillary Temperatures
TAKING AXILLARY TEMPERATURES - BLUE CAPPED PROBE Axillary temperatures should only be taken when the 767 SureTemp 4™ is in the Monitor mode with an oral probe. 1. Set the thermometer to the Monitor mode. Attach a probe cover onto the probe. -
Page 22: Cleaning And Sterilization
CLEANING & STERILIZATION The 767 SureTemp 4™ housings may be cleaned with a cloth dampened with alcohol, warm water, or a nonstaining disin- fectant such as Sporicidin® Spray and Towelettes or MetriSpray™. Care should be taken not to scratch the LCD faceplate. -
Page 23: Limited Warranty
LIMITED WARRANTY 3-YEAR LIMITED WARRANTY ON NEW INSTRUMENTS Instrumentation purchased new from Diatek Instruments, Inc. (Diatek) is warranted to be free from original defects in material and workmanship under normal use and service for a period of three years from the date of first shipment from Diatek. - Page 24 (800) 854-2904 • (619) 621-6600 • FAX (619) 621-6610 Diatek Instruments, Inc. 7420 Carroll Road, San Diego, CA 92121-2334 70826-0000A...
