Channel Packet Parameters

Channel Packet Bytes 0 and 1 (len)

The len parameter (bytes 0 and 1) hold the 16-bit length of the packet (Table 3). The packet length is
always 218 bytes.
len = Length (in bytes) of total packet (including header)
Data Packet Size

Table 14 Channel Packect len header parameter

Channel Packet Bytes 2 and 3 (type)

The type parameter (bytes 2 and 3) is 16-bits packet type and is always 0x003 for channel data.
type = Packet type
Channel Data
Table 15 type header parameter

Channel Packet Bytes 4 and 5 (seq)

Bytes 4 and 5 hold the 16-bit sequence number (see Table 5). The sequence number is used as a
method to detect if and when data packets are dropped, so it is important to ensure that consecutive
sequence numbers are transmitted for channel data packets during operation.
