Net-2000™ Voice Codec Unit
User's Manual
Note:
The Ethernet MAC address and default hostname of the VCU is derived from the serial
number of the VCU. The MAC address will begin with 00:01:FD followed by the last six
digits of the serial number. The hostname is NET2K followed by the last four digits of the
serial number. For example, if the last six digits of the serial number are 301234, the
MAC address is 00:01:FD:30:12:34 and the hostname is NET2K1234.
When no DHCP server is available on a LAN the VCU's RS-232 serial port can be used as a console
terminal for low-level network setup. With the serial cable connected and the terminal running type a
few carriage returns from the PC's keyboard. The Net-2000™ VCU will respond with the console
prompt as shown below:
adsh>
At the adsh prompt the VCU's network settings can be configured or changed using the terminal
console command "network" as follows:
adsh>network [-dhcp] [-h hostname] [-w workgroup] [-i ipaddress] [-m
netmask] [-g gateway] [-n nameserver][-d domainname]
The arguments to the network command are described below:
Arguments
-dhcp when DHCP is available on LAN
-h
-w
-i
-m
-g use only when DHCP is disabled
-n
-d
Table 3 DHCP Set-up command Arguments
The following command example results are shown in the table below
adsh>network –h net2k1234 -w lab -i 192.168.1.100 -m 255.255.255.0 -g
192.168.1.250 -n 192.168.1.1 -d domain.com
Arguments
-h
-w
-i
-m
-g
-n
-d
Table 4 DHCP Setup Example
NOTE: Do not mix the -dhcp argument with the -i -m –d -g -n arguments.
DVSI Confidential Proprietary
Use
anytime
VCU Result
DHCP is NOT enabled
HOSTNAME
Windows WORKGROUP
STATIC IP address
NETMASK IP address
GATEWAY IP address
NAMESERVER IP address
VCU DOMAIN NAME
Section 3 – Net-2000™ VCU Control
Result
DHCP is enabled
Sets the hostname of the VCU
Sets the Windows workgroup of the VCU
Sets the static IP address
Sets the IP address of the netmask
Sets the IP address of the gateway
Sets the IP address of the nameserver
Sets the domain name of the VCU.
Example
net2k1234
lab
192.168.1.100
255.255.255.0
192.168.1.250
192.168.1.1
domain.com
Page 8
