Warranty coverage is null and void unless the Warranty Registration form has been completed in full and is on fi le at MK Martin Enterprise Inc. Warranty begins at the time of customer delivery and is activated upon Warranty Registration receipt at MK Martin Enterprise Inc.
Page 5
M K Martin Enterprise Inc 3950 Steffl er Rd Elmira ON CA N3B 2Z3 --------------------------------------------------------------------------------------------------------------------- Purchaser’s warranty protection is valid only when this completed form or a copy of this form is on fi le at M K Martin Enterprise Inc. By fi lling out this form the purchaser has acknowledged delivery of equipment and owner’s / operator’s manual and has accepted the condition of the equipment.
Warranty Registration Please Cut and Return to M K Martin Enterprise Inc Fold And Tape here Do not tape all edges or use staples Fold Here ------------------------------------------------------------------------------------------------------------------------- Postage Stamp M K Martin Enterprise Inc 3950 Steffl er Rd Elmira ON CA N3B 2Z3...
Safety Take Note! This safety symbol is found throughout this manual to call your attention to instruc- tions involving yourself and others working around the machine. • Failure to follow these instructions can result in injury or death This symbol means -- Attention! -- Become Alert! -- Your Safety is involved!
Page 8
Maintain and keep tires in good condition. Have a qualified serviceman perform the required maintenance. Ensure that all decals are legible. See your dealer parts department for replacements. WARNING ! Always block Land Leveler securely before working on or under Land Leveler.
Page 9
Hydraulic Leak Test Warning! Do not check for high pressure leaks with your hands or fi ngers. Use a piece of cardboard or a thin piece of wood to detect the leak. A high pressure stream of fl uid from a pin hole can penetrate the skin and inject hydraulic fl uid into your blood veins.
Decal Location and leveller\Levelers_updated\10FT Lift And Tilt.SLDASM # 1 - Land Leveler Decal - x2 DETAIL A SCALE 1 : 18 Folder S:\Solidworks\Solidworks_Dennis\Land leveller\Levelers_updated\ Notes DIMENSIONS ARE IN INCHES TOLERANCES NON SPECIFIED: 10FT Lift And Tilt FRACTIONAL 1/64 DWG. NO.
Page 11
Assembly Information • The Land Leveler is shipped as a package that includes; • Main Mouldboard Assembly • Rear Axle Beam with Tilt. • Tongue with Hitch • Tongue Braces ( for 10 and 12 foot ) • Wheels • Jack •...
Page 12
Operating The leveler will work better and easier if the soil is plowed and disked before leveling. The Land Leveler blade is situated between the tractor wheels and the leveler wheels and will shave or plane off the high areas and fill in low areas. For leveling purposes’ adjust the rear wheels with the hydraulic cylinder so that the rear tractor wheels, the cutting edge and the rear leveler wheels form a straight line as shown.
Sign Off Form M K Martin Enterprise Inc. follows the general Safety Standards specifi ed by the American Society of Agricultural Engineers (ASAE) and the Occupational Health and Safety Administration (OSHA). Anyone who will be operating and/or maintaining the equipment must read and clearly understand ALL Safety Operating and Maintenance instructions presented in this manual.
Land Leveler Parts Item # Part # Description 8 ft 10 ft 12 ft 10917 Wear Bar 10916 Wear Bar Clamp xzhcs6220nc Bolt 5/8 x 2 c/w ln 53918 8ft Cutting Edge 52787 10ft Cutting Edge 12ft Cutting Edge xbpb6215nc...
Page 15
Land Leveler Parts Item # Part # Description 8 ft 10 ft 12 ft 10191 8 Ft Tongue 30981 10 & 12 Ft Tongue xzhcs7520nc Bolt 3/4x2 c/w ln 508-021 Self Drilling Screw 1/4 x 1 52649 Manual Tube 32502...
Page 16
Land Leveler Tilt Axle 2 3 4 16 15 14 Item # Part # Description 8 ft 10 ft 12 ft 53919 9/16 Wheel Stud 53920 Dust Cap 53921 Castle Nut 53922 Outer Bearing 53930 8 ply tire 53925 Hub 4000...
Page 17
Land Leveler Tilt Axle Item # Part # Description 8 ft 10 ft 12 ft 31790 Tilt Axle 8ft - 10ft 31792 Tilt Axle 12ft 31789 Tilt Frame 8ft - 10ft 31791 Tilt Frame 12ft 52657 3/4 x 6 1/4 Hitch pin...
• Read Operator’s Manual • Check all bolts for proper torque • Grease Pivot Pins WARNING ! Always block Land Leveler securely before working on or under Land Leveler. After first 2 hours 1. Re-torque all bolts including wheel bolts 2.
Bolt Torque As used on this machine • Bolt torque table shown below gives torque values for various bolts used. • This chart is for non-lubricated threads. • Replace with same strength bolt. Torque Specifi cations. Torque values are identifi ed by their head markings. Diameter SAE 2 SAE 5...
Page 20
MK Martin Enterprise Inc. 3950 Steffl er Rd Elmira, ON, Canada N3B 2Z3 Tel: 519-664-2752 Toll Free: 1-855-664-2752 Fax: 519-664-3695 E-mail: sales@mkmartin.ca www.mkmartin.ca...
