- Page 1 Operator’s / Parts Manual MK Martin Enterprise Inc. 3950 Steffl er Rd Elmira, ON, Canada N3B 2Z3 Tel: 519-664-2752 Toll Free: 1-855-664-2752 Fax: 519-664-3695 E-mail: sales@mkmartin.ca www.mkmartin.ca Rev:18-1...
-
Page 3: Table Of Contents
Operation ----------------------------------------------------------------------------------------------- • Sign Off Form ----------------------------------------------------------------------------------------- • Shank Spacing ---------------------------------------------------------------------------------------- 10-11 • Track Curry Parts ------------------------------------------------------------------------------------- 12-13 • Track Curry Wing Parts ----------------------------------------------------------------------------- • Notes ---------------------------------------------------------------------------------------------------- • Sprinkler System Parts ----------------------------------------------------------------------------- 16-17 • Sprinkler Operation ---------------------------------------------------------------------------------- 18-19 • Maintenance ------------------------------------------------------------------------------------------- •... -
Page 4: Warranty
Warranty coverage is null and void unless the Warranty Registration form has been completed in full and is on fi le at MK Martin Enterprise Inc. Warranty begins at the time of customer delivery and is activated upon Warranty Registration receipt at MK Martin Enterprise Inc. - Page 5 M K Martin Enterprise Inc 3950 Steffl er Rd Elmira ON CA N3B 2Z3 --------------------------------------------------------------------------------------------------------------------- Purchaser’s warranty protection is valid only when this completed form or a copy of this form is on fi le at M K Martin Enterprise Inc. By fi lling out this form the purchaser has acknowledged delivery of equipment and owner’s / operator’s manual and has accepted the condition of the equipment.
-
Page 6: Registration
Warranty Registration Please Cut and Return to M K Martin Enterprise Inc Fold And Tape here Do not tape all edges or use staples Fold Here ------------------------------------------------------------------------------------------------------------------------- Postage Stamp M K Martin Enterprise Inc 3950 Steffl er Rd Elmira ON CA N3B 2Z3... -
Page 7: Safety
Safety Take Note! This safety symbol is found throughout this manual to call your attention to instruc- tions involving yourself and others working around the machine. • Failure to follow these instructions can result in injury or death This symbol means -- Attention! -- Become Alert! -- Your Safety is involved! - Page 8 Safety -- It,s in your interest! You are responsible for the safe operation and maintenance of your Track Curry. You must ensure that you and anyone else who operate the Track Curry are properly trained to operate it. Annually refresh yourself and all other operators on the safe use of the Track Curry.
-
Page 9: Decals
S:\Solidworks\Solidworks_Elo\Trac Curry\6 Ft Track Curry.SLDASM Decal Locations Folder Notes S:\Solidworks\Solidworks_Elo\Trac Curry\ DIMENSIONS ARE IN INCHES TOLERANCES NON SPECIFIED: 6 Ft Track Curry FRACTIONAL 1/64 DWG. NO. DATE DRAWN February-26-09 3:38:40 PM BEND 30164 TWO PLACE DECIMAL 0.01" Config ID MATERIAL THREE PLACE DECIMAL 0.002"... -
Page 10: Assembly
Track Curry. 5. Adjust the leveler blade and the rear drum height to suit your needs. 6. The Track Curry is designed to handle Cat #1 ASAE Quick Coupler and Cat #1 Free Link and JD “I” Match. Operation The Track Curry is designed to renovate and condition horse arenas and tracks in a single pass. -
Page 11: Sign Off Form
Sign Off Form M K Martin Enterprise Inc. follows the general Safety Standards specifi ed by the American Society of Agricultural Engineers (ASAE) and the Occupational Health and Safety Administration (OSHA). Anyone who will be operating and/or maintaining the equipment must read and clearly understand ALL Safety Operating and Maintenance instructions presented in this manual. -
Page 12: Shank Spacing
Shank Spacing 5’ - 13 Shanks 6’ - 15 Shanks... - Page 13 Shank Spacing 7’ - 17 Shanks 8’ - 19 Shanks...
-
Page 14: Track Curry Parts
Track Curry Parts S:\Solidworks\Solidworks_Elo\Trac Curry\6 Ft Track Curry.SLDASM 16 17 18 10 11 14 15 12 13 Item # Part # Description TC-5 TC-6 TC-7 TC-8 54068 Cultivator Point - Bolt 5’ Folder Notes S:\Solidworks\Solidworks_Elo\Trac Curry\ DIMENSIONS ARE IN INCHES... - Page 15 Track Curry Parts Item # Part # Description TC-5 TC-6 TC-7 TC-8 Bolt 1/2x3 1/2 c/w ln 53315 Spill Plate 52635 Gauge Drum 5’ 52630 Gauge Drum 6’ 52634 Gauge Drum 7’ 52632 Gauge Drum 8’ 54070 Bearing 30009 Bearing Bracket...
-
Page 16: Track Curry Wing Parts
Wing Holder 53192 Wing Blade 53193 Wing Clamp S:\Solidworks\Solidworks_Elo\Trac Curry\Scarifier\36277.SLDASM Bolt 1/2 x 1 1/2 c/w lw, n Track Curry Opt. Scarifier Bar Parts DETAIL F SCALE 1 : 16 Folder Notes DIMENSIONS ARE IN INCHES S:\Solidworks\Solidworks_Elo\Trac Curry\ TOLERANCES NON SPECIFIED:... -
Page 17: Notes
NOTES... -
Page 18: Sprinkler System Parts
Curry\sprinkler system.SLDASM Track Curry Opt. Sprinkler System Parts 14 20 Back Front Item # Part # Description 60000 Left side leg Folder S:\Solidworks\Solidworks_Elo\Trac Curry\Track Curry Sprinkler\ Notes DIMENSIONS ARE IN INCHES Bolt 1/2 x 1 1/4 c/w lw, n... - Page 19 Track Curry Opt. Sprinkler System Parts Item # Part # Description 54075 Battery cable 54101 1/2 Tees 54091 Relief valve 60010 Bypass line 54092 Hose Clamp 60008 Boom supply hose 54102 Nozzle body triple 54103 Nozzle body 1 HB 60007...
-
Page 20: Sprinkler Operation
Sprinkler System Operation CAUTION: “Intermittent Duty” is defined as; operated and/or frequently started within a period of time that would cause the motor to reach its maximum thermal limits. Once the maximum thermal limit is obtained, the motor must be allowed to return to ambient temperature before resuming operation. - Page 21 Sprinkler System Operation CAUTION: Circuit protection is dependent on the individual application requirements. Failure to provide proper overload / thermal devices may result in a motor failure, which will not be covered under warranty. TROUBLESHOOTING PUMP WILL NOT START: PUMP WILL NOT SHUT-OFF: (Pressure switch equipped) •...
-
Page 22: Maintenance
Maintenance The Track Curry is a low maintenance product. • Evey 5-6 hours lightly grease the Drum Bearings. (One or two shots of grease.) • Periodically check for loose bolts and tighten as required. Storing • Store in a dry place on blocks or wood if possible. - Page 24 MK Martin Enterprise Inc. 3950 Steffl er Rd Elmira, ON, Canada N3B 2Z3 Tel: 519-664-2752 Toll Free: 1-855-664-2752 Fax: 519-664-3695 E-mail: sales@mkmartin.ca www.mkmartin.ca...
