Textron EZGO TXT FREEDOM Service & Parts Manual page 90

SEATING
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO.
20 01107G01
21
22
23 605056
24 00664G7
25 01075G01
26 11027G2
27 618206
28 610642
29 608051
30 71853G01
31 16816G1
32 01102G01
33 71811G03
Page L-3
1 2 3 4 5
PAN HEAD TORX SCREW, #8 - 5/8 X .63" LG ........................................
HEX HEAD BOLT (SS), 1/4" - 20 X 1" LG .......................................................
LOCK WASHER (SS), 1/4" .............................................................................
HEX HEAD BOLT, 3/8" - 16 X 2 1/2" LG..........................................................
LOCK NUT, 1/4" - 20 .......................................................................................
BAG HOLDER ASSEMBLY (INCLUDES ITEMS 28 - 29) ...............................
BAG HOLDER BRACKET.........................................................................
BAG RETAINER CLAMP ..........................................................................
BAG RETAINER STRAP .................................................................................
RATCHET FASTENER, 1/4" X 9/16" LG .........................................................
CARRIAGE BOLT (SS), 1/4" - 20 X 1 1/2" LG.................................................
SEAT SUPPORT BRACKET ...........................................................................
658755 Service Parts Manual
DESCRIPTION QTY.
4
4
4
4
2
1
1
2
1
2
2
2
