4.5 Display
3
4

5. Assembly Instruction

Turn the main instrument lock clockwise to connect titrating tip with main body. It is possible
-
that this step has already been done.
Place the titrating pipe tail end into the location slot.
-
Push the titration tail tube to a certain extent, so that the end of the tube protrudes from the
-
main body.
Connect the titration pipe tail end with the dispensing valve.
-
1
2
5
7
1. Battery indicator
2. Unit
3. Magnetic stirring indicator
4. Indication arrow (piston movement)
5. Liquid volume
