LABBOX EASY 70 User Manual page 14

Press the black button on the clamp and introduce the holder through, release the button when
-
is located at the desired height and the clamp will remain fixed.
Insert the smallest metal bar into the groove of the largest one so the support is well fixed.
-
Assembly diagram
8.3. Remote Titrating pipe
Remote titrating pipe can effectively extend the titration distance. It shall be placed on the holder
clamp. To install it, follow up the instructions:
MAX. Length 1.5m
