▲ Product Overview

①External water tank connection port (φ8 quick connector)
②Fuse
③Power Socket
④3-Pin DMX IN
⑤3-Pin DMX OUT
⑥Power ON/OFF
⑦LCD Control Panel
⑧Water Filling Port, Fluid Tank
⑨Liquidometer
⑩Fog output pipe
▲ LCD Control Panel Operation
a) LED display area
MENU: switch through setup menu；
+: Parameter up; multiplex "TIMER" (smoke output time)
-: Parameters down; multiplex "VOLUME" (smoke output start)
ENTER: confirm and save parameters (screen will blink once parameter saved); multiplex
"STOP".
NOTE: Screen will switch to main interface automatically if not press any button in long time.
SHOWVEN Creeper AQ mini Low Fog Generator USER MANUAL -3-
