- Page 1 1000W Monoblock Class D Marine Subwoofer Amplifier with CONNECTION GUIDE 13.34 in 339 mm 6.93 in 3.67 in 176 mm 93 mm 2.05 in 52 mm 5 6 7 13.96 in 355 mm...
- Page 2 For maximum performance, we highly recommend that you have your new amplifier installed by an authorized JL Audio dealer. Your authorized dealer has the training, expertise and installation equipment to ensure optimum performance from this product. Should you decide to install the amplifier yourself, please take the time to read this manual thoroughly to familiarize yourself with its installation requirements and setup procedures.
- Page 3 Cooling Efficiency Considerations The outer shell of your JL Audio amplifier is designed to remove heat from the amplifier circuitry. For optimum cooling performance, this outer shell should be exposed to as large a volume of air as possible. Enclosing the amplifier in a small, poorly ventilated chamber can lead to excessive heat build-up and degraded performance.
- Page 4 Wiring Diagram - MV1000/1 Included Not Included Attached to Amp +12 VDC - Positive (+12V) Battery Connection Ground - Negative (–) Ground Connection Remote - Positive (+12V) Turn-On Input From Source Unit CH. 1 - Ch. 1 Signal Input ANALOG INPUTS CH.
- Page 5 Limited Warranty – Marine Amplifiers (USA) JL Audio warrants this product to be free of defects in materials and workmanship for a period of two (2) years from the original date of purchase. This warranty is not transferable and applies only to the original purchaser from an authorized JL ...
