QUICK SETUP GUIDE
Read the manual carefully and ensure you have fully understood its contents before operating this device for the first time.
English
ES-A2113Z1-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Laser Cinema 120 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hisense Laser Cinema 120

  • Page 1 QUICK SETUP GUIDE Read the manual carefully and ensure you have fully understood its contents before operating this device for the first time. English ES-A2113Z1-1...
  • Page 2 ▌Important Notice Paragraphs beginning with the symbol indicate important instructions, tips or conditions for the following settings. For your own safety and the optimal performance of your device, ensure to read the safety instructions before performing any installation. Compatibility with 3rd party products, software and services are not guaranteed. We cannot be held liable for any damage or loss suffered whilst operating, using or connecting to incompatible devices or apps.
  • Page 3 ▌Safety Instructions To ensure safe and correct use of this product, always comply with the following precautions to avoid dangerous situations and damage to your unit: The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock.
  • Page 4 „ Power Supply „ Power plug and power cable Incorrect voltages can damage the device. Only connect this unit - Do not touch the power plug with wet hands. to a power supply with the correct voltage and frequency noted - Do not place heavy objects on the power cable.
  • Page 5 or temporarily stop using headphones. tablecloths, curtains, etc. - Do not dry clothing etc. on top of the unit. „ Thunder Storms - Take care not to touch the ventilation openings since they may become hot. Pull out the power plug and all connected antenna cables from - Do not insert foreign objects into the device through the vents.
  • Page 6 damaged. Take care not to scratch it with fingernails or other - Do not mix different battery types. hard objects. - Do no use rechargeable batteries. - Also wipe the power plug with a dry cloth at regular intervals. - Do not burn or break up batteries. - Be sure to dispose of batteries correctly.
  • Page 7 - If any object or water enters this device, please unplug this - Do not place any object above or in front of the lens device and contact the service staff of Hisense. because the laser light could cause the object to become flammable.
  • Page 8: Table Of Contents

    Congratulations on the purchase of your new Laser Cinema! This Manual will walk you through a few easy steps to set up your Laser Cinema. Please visit Hisense official website for more details. Product image is only for reference, actual product may vary in appearance.
  • Page 9: Accessories List

    • Do not allow a child to stand on or climb up this device. • Do not place any object above or in front of the lens because the laser light could cause the object to become flammable. • Clean the lens periodically with a clean cloth and make sure the Laser Cinema is turned off before you start. Accessories List •...
  • Page 10: Laser Cinema Diagram

    Laser Cinema Diagram Power Indicator Air vents Remote control receiver Power button protection Lens with sensor laser We strongly recommend that two people handle this device when moving it from one place to another. Be sure to protect the lens when you handle this device.
  • Page 11: Step 1 Mount The Screen

    STEP 1 Mount the Screen Screen installation please refer to the specific screen installation guide! STEP 2 Install the Laser Cinema We strongly recommend that two people handle this device when moving it from one place to another. Be sure to protect the lens when you handle this device.
  • Page 12 USB 1 DC 5V 0.5A(MAX) SERVICE 1 AUDIO IN USB 2 DC 5V 0.5A(MAX) 3.5mm stereo VIDEO HDMI 1 HDMI 3 (4K@60Hz) (4K@60Hz) HDMI 2 HDMI 4 Computer (4K@60Hz) (4K@60Hz) Ethernet (you will need a router for Internet connectivity) DIGITAL AUDIO OUT SERVICE 2 CAM CARD...
  • Page 13 NOTE: Use the USB extension cable (included) for easier connection and disconnection. When connecting a hard disk or a USB hub, always connect the mains adapter of the connected device to the power supply. Exceeding a total current consumption may result in damage. The USB1.1 and USB2.0 devices maximum current consumption are 500mA.
  • Page 14 Wired setup LAN ( Connect your Laser Cinema to your network by connecting the LAN port on the back of your Laser Cinema to an external modem or router using a LAN (Ethernet/Cat 5) cable. See the illustration below. Laser Cinema PORT IP Sharer (Router) External Modem (with DHCP server)
  • Page 15 1. Plug the power cord into a wall outlet. WARNING: Insufficient ventilation space will cause 2. Press the POWER button to turn on the Laser Cinema. this device to overheat or become damaged. • Do not block the air vents or place any object on this device. •...
  • Page 16: Step 3 Adjust The Display Image And The Screen

    STEP 3 Adjust the Display Image and the Screen Follow the steps in the order shown below, only if they apply to your situation. NOTE: Before adjusting, fold the wall-mount bracket wands so that screen is vertically level. Rotate feet from an overlooking view, but do not look directely at the lens when the Laser Cinema is on because the laser light may damage your eyes.
  • Page 17 • If the bottom of the image is wider than the screen, then ADJUST THE UPPER-RIGHT CORNER OF THE IMAGE move the Laser Cinema closer to the screen. 1. If the top of the image is lower on the left and higher on the right, then use the wrench to rotate the front-right foot and the back-right foot clockwise to the same height.
  • Page 18 height. 4. If the upper-right corner is inside the screen after adjusting, use the wrench to rotate the front-right foot and the back- 2. Now, rotate the Laser Cinema clockwise so that the bottom of right foot counterclockwise to the same height, and rotate the Laser Cinema clockwise, to make the image parallel with the screen.
  • Page 19 FILL THE TOP OF THE IMAGE TO THE SCREEN If the top of the image is wider than the screen, then use the wrench to rotate the left- and right-front feet of the Laser Cinema clockwise. If the top of the image is narrower than the screen, then use the wrench to rotate the left- and right-back feet of the Laser Cinema clockwise, until the left and right borders of the image are parallel with the screen borders.
  • Page 20: Step 4 Use Your Remote

    STEP 4 Use Your Remote BUTTONS ON YOUR TV REMOTE NOTE: The button labels are provided as a reference. The actual appearance of the remote that is included with the TV, may differ from this diagram. Microphone / Power indicator Select input sources Power Standby button: Power on / Standby Custom button to launch input or apps quickly...
  • Page 21 BUTTONS ON YOUR TV REMOTE NOTE: The button labels are provided as a reference. The actual appearance of the remote that is included with the TV, may differ from this diagram. Power Standby button: Power on/ Standby Display the current program information Select a channel or input numbers Playpad keys Display the Electronic Program Guide (DTV...
  • Page 22 • If you do not intend to use the remote control for a long time, 1. Press the switch and the battery case then remove the batteries. will pop up automatically. • Battery chemicals can cause a rash. If the batteries leak, 2.
  • Page 23 PAIRING THE REMOTE CONTROL (ONLY FOR BLUETOOTH REMOTE CONTROL) 1. Pair the remote to the Laser Cinema after you power it on. Keep the remote control within 3 metres from the Laser Cinema. Press and hold the [ ] button at least 3 seconds to start pairing.
  • Page 24: Step 5 Proceed Through The Screen Setup Menu

    STEP 5 Proceed through the Screen Setup Menu PROJECTION MODE If you need to flip the image over top-to-bottom and/or left-to- right, select the Projection Mode. Alignment grid AUTO GEOMETRIC CORRECTION Before you use Auto Geometric Correction function, ensure that 4.
  • Page 25: Step 6 Laser Cinema Setup

    Select the Country where you will operate 3. Press button to save your adjustment, and you can select Country the Laser Cinema. other points to adjust the image. If you want to return the image position to the factory default, Select the local time zone according to Time Zone your region.
  • Page 26: Maintenance & Quick Problem-Solving Tips

    Maintenance • Do not touch this device when it is running or just turned off because it may be hot. • Do not wipe this device with oil because it may deteriorate the exterior or damage the paint. Contact with rubber or ethylene products for a long time may cause stains on this device.
  • Page 27 2. Make sure you have made the correct selection for the input mode for the incoming signal. The picture is normal but there is no sound 1. Check the volume settings. 2. Check if 'Mute' mode is set to On. Sound but no picture or black and white picture 1.
  • Page 28: Product Specifications

    Product Specifications Model Name 120" Laser Cinema 21.5 × 6.2 × 13.6 inches Dimension (W × H × D) (547 × 158 × 346 mm) Weight 25.4 lbs (11.5 kg) Active Screen Size (Diagonal) 120 inches Screen resolution 3840 × 2160 Audio power 2 ×...
  • Page 29 Model ZDGFMT7668AU Bluetooth Module Frequency Range 2.400~2.485GHz specifications Output Power (Max.) 2.400~2.485GHz, Class1, 7dBm Model ERF6A64 / ERF6B64H Remote Control Frequency Range 2.400~2.4835GHz specifications Output Power (Max.) 2.400~2.4835GHz 5dBm Temperature: 41°F - 104°F (5°C - 40°C) Environmental conditions Humidity: 20% - 80% RH Atmospheric pressure: 86 kPa - 106 kPa RGB / 60 Hz (640×480, 800×600, 1024×768) YUV / 60 Hz (480 I, 480 P, 720 P, 1080 I, 1080 P)
  • Page 30: Recycling / Licenses

    Recycling / Licenses The terms HDMI and HDMI High- Definition Multimedia Interface, and This symbol on the product or on its packaging indicates that the HDMI Logo are trademarks or this product must not be disposed of with your household registered trademarks of HDMI Licensing waste.
