Installation Guide
5-Port 10G Multi-Gigabit Desktop Switch
Note:
The images in this guide are only for example and may not reflect your actual experience.
Connection
Power Adapter
Router
WAN Port
LAN Port
Panel Explanation
Power
On: Power on
Off: Power off
Port
When one of the LED is on/flashing:
10G/5G
2.5G/1G/100M
On: Connecting to a device but no activity.
Flashing: Transmitting or receiving data.
Left LED (10G/5G):
Green: Running at 10 Gbps.
Amber: Running at 5 Gbps.
Right LED (2.5G/1G/100M):
Green: Running at 2.5 Gbps.
Amber: Running at 100/1000 Mbps.
TL-SX105
10G
Workstation
NAS/Server
Kensington Security Slot
Secure the lock (not provided) into
the security slot to prevent the
device from being stolen.
Ethernet Ports (1–5)
Gaming
8K Video
2.5G
Computer
Wi-Fi 6 AP
