Detecto PL600 Specifications

D E T C O
A Division of Cardinal Scale Manufacturing Co.
Detecto's Patient Lift Scale is a completely self-contained instrument that determines the weight of a
person suspended from a portable patient lift mechanism. The indicator incorporates a lock weight
feature which stores the last weight reading when the unit is turned off and can be used where
standard indicators are too large and cumbersome. It operates on only one (1) 9-volt Alkaline battery;
battery-power is saved due to the automatic shut-off feature. The scale also has a membrane keypad
with only three (3) keys: ON/ZERO, OFF and LB/KG. Its so easy to setup and operate, the procedure
is quickly learned.

Capacity:

Display:

Power:

Cardinal Scale reserves the right to improve, modify, or enhance features and specifications without prior notice.
Ph: 417-673-4631 • Fax: 417-673-5001
P.O. Box 151, Webb City, MO 64870 USA
Web site: http://www.detectoscale.com
E T
®
PL400: 400 lb x 0.2 lb
180 kg x 0.1 kg
PL600: 600 lb x 0.2 lb
270 kg x 0.1 kg
LCD digital
9-volt battery (included)
Ship Weight: 2 lb
Scale supplied with two (2) Spring "0" rings

Specifications

Temperature
Range:
Mounting
Holes:

Dimensions:

DIGITAL
PATIENT
LIFT SCALE
50 to 104½F
(10 to 40½C)
1/2" diameter, 4" to center
4 1/8"W x 2 1/8"D x 5"H
F-C158A
