Summary of Contents for BAFANG BT C01. UC Series
-
Page 1: Table Of Contents
8 USER MANUAL FOR BT C01.XXX.UC CONTENT 8.1 Instructions 8.2.1 Installing the Battery 8.2.2 Removing the Battery 8.1.1 Battery 8.2.3 Charging the Battery 8.1.1.1 Safety Instructions 8.2.3.1 Safety Instructions 8.1.1.2 Battery Storage 8.2.4 LED Display for Charge Status and Charging Capacity 7 8.1.1.3 Battery Wear 8.2.4.1 Sleep State 8.1.1.4 Pedelec Riding Distance... -
Page 2: Instructions
A faulty battery can lead to overheating, smoking or burning. When the battery gets hot keep yourself and Please only use the original BAFANG charger to others a safe distance away from the battery. In charge the battery. The battery is not fully case of damage or heat, you should avoid charged when it is delivered. -
Page 3: Battery Storage
Do not intentionally short-circuit the • To prevent a deep discharge, the battery is battery. put into sleep mode after a certain time. Never allow the plus and minus connectors to • Do not extend the battery to temperatures come into contact with each other. Do not below the permissible storage temperature allow the battery to come into contact with of -10 °C to 35 °C. -
Page 4: Charger
Avoid direct sunlight. • Disconnect the charger from the power supply when not in use. • Use only the original Bafang charger that came 8.1.2.1 Battery charger Instructions with your pedelec. Read the instructions on the external label of •... -
Page 5: Operation
8.2 OPERATION 8.2.1 Installing the battery 3. Once the battery is inserted, the battery can be locked. Then remove the key to avoid losing or damaging For correct insertion, the battery must be inserted and pushed forward from the back of i t . -
Page 6: Charging The Battery
8.2.3 Charging the battery charging time of your battery, see "SPECIFICATION" When the battery is fully charged, the charging Use only the original battery charger supplied to process stops automatically. Unplug the connec- you, as there is a risk of fire or explosion if the tor from the battery and then removed from the incorrect charger is used. -
Page 7: Led Display For Charge Status And Charging Capacity
Errors - Causes and Solutions Description Cause Solution Power plug is not cor- Check that all connectors on the The operating display does not rectly connected to the charger are correctly connected to light up. power supply the power supply. The battery may be mal- The charging indicator is not lit. -
Page 8: Specifications
8.3 SPECIFICATIONS 8.3.1 Battery Primary Settings BT C01.340.UC BT C01.450.UC BT C01.600.UC BT C01.750.UC Rated voltage 43 DCV 43 DCV 43 DCV 43 DCV Nominal Capacity 7.8 Ah 10.4 Ah 14 Ah 17.5 Ah 6.43 Ah 8.5 Ah 11.4 Ah 14.3 Ah Rate Capacity (1C Discharge) - Page 9 BF-UM-C-BT C01-EN October 2019...
- Page 10 BF-UM-C-BT C01-EN October 2019...
- Page 11 BF-UM-C-BT C01-EN October 2019...
- Page 12 BF-UM-C-BT C01-EN October 2019...
