Page 1: Table Of Contents
8 USER MANUAL FOR BT F07.450.C/ BT F08.600.C CONTENT 8.1 Introduction 8.2.1 Installing the battery 8.2.2 Removing the battery 8.1.1 Battery 8.2.3 Charging the Battery 8.1.1.1 Safety Instructions 8.2.3.1 Safety Instructions 8.1.1.2 Battery Storage 8.2.4 LED Display for Charge Status and Charging Capacity 7 8.1.1.3 Battery Wear... -
Page 2: Introduction
·Please carefully read manual before use. carefully with clean water and consult a doctor or a hospital. Please only use the original BAFANG charger A faulty battery can lead to overheating, to charge the battery. The battery is not fully smoking or burning. -
Page 3: Battery Storage
Do not disassemble the battery. • Avoid direct sunlight from the sun, as it may The battery contains protective components to cause it to overhead, and cause internal avoid danger. Incorrect handling, such as problems in the battery. It can lead to abnor- improper disassembly, can destroy the protective mal chemical reactions or malfunctions that functions and lead to overheating, smoke and... -
Page 4: Charger
• Disconnect the charger from the power supply when not in use. • Use only the original Bafang charger that came with your pedelec. • Do not cover the charger while in use. There is the possibility of short circuits or fires. -
Page 5: Operation
8.2 OPERATION 8.2.1 Installing the battery 8.2.2 Removing the battery 1. Turn the key on the battery holder to open For correct insertion, the battery must be lock. connected, ensuring all pins are correctly connected to the battery holder. When pushing the battery into position. -
Page 6: Charging The Battery
8.2.3 Charging the battery The charging time depends on several factors. It can vary greatly depending on the temperature, age, use and capacity of the battery. For information on Use only the original battery charger supplied to the charging time of your battery, see "SPECIFICA- you, as there is a risk of fire or explosion if the TION". -
Page 7: Led Display For Charge Status And Charging Capacity
The battery must be charged at least once every If the charging process takes longer than usual, 3 months to avoid damage or destruction of the the battery may be damaged. In this case, stop cells. charging immediately. Have the battery and charger checked by your retailer to prevent further damage. -
Page 8: Specification
8.3 SPECIFICATION 8.3.1 Battery Primary Settings BT F07.450.C BT F08.600.C Rated voltage 43 DCV 43 DCV Nominal Capacity 10.5 Ah 14Ah Rate Capacity 8.5Ah (1C Discharge) 11Ah (1C Discharge) Power 450 Wh 600Wh Charging time 6.5h with 2A Charger 8.5h with 2A Charger Storage (At 35% SOC &-10°...
