SECTION 1: UNPACKING DVDM-800

Here's what you should find in the DVDM-800 box:
1
DVDM-800 unit with
DVD player and 8"
LCD monitor
MV10002-11B1 (Gray, 1-year warranty)
MV10015-11B1 (Neutral, 1-year warranty)
MV10017-11B1 (Gray, 3-year warranty)
MV10016-11B1 (Neutral, 3-year warranty)
Note: Installation materials sold separately include a shroud for a professional fit. Delphi highly recommends that you contact a professional to
ensure proper installation. To locate a professional installer in your area, contact your retailer.
It is your sole responsibility that installation is completed properly and will not result in personal injury, death, and/or damage to your
DVDM-800 and/or to your vehicle.

SECTION 2: FEATURES

Disk slot
Power
Turns DVDM-800 on or off.
Front infrared screen
Transmits audio to infrared (wireless)
headphones and receives infrared
signals from the remote control.
Dome light
LCD panel release
Releases the LCD panel.
Air intake vents
Adjuster knob
Adjusts the angle of the screen panel.
Light sensor
Thin film transistor video monitor
Control buttons
(See Section 3.)
A/V 3 inputs
2
Two sets of wireless
headphones (requires 2 AAA
batteries, included)
7 8
Wireless FM transmitter
(factory installed)
4
Power cable
3
Remote control (requires
2 AAA batteries, included)
6
9
Galvanized steel
User Manual and
mounting bracket
Installation Guide
A green backlit LED indicates disc
slot location so users can see where
to insert a disc. The LED is off when
Stops play. Press again to eject
when power is on. Eject functions
Turns the dome lights on, or sets
them to turn on automatically
Turns screen off when panel is
closed. (Audio continues to function.)
5
A/V cable
A/V connection box
10
Screws and
spacers
Slot indicator
there is a disc in the player.
Eject
EJECT
disc. Button is backlit orange
even when unit is off.
Dome light
Dome light switch button
when the vehicle's interior
lighting is activated.
Reset pin hole
Screen power switch
Rear infrared screen
For remote control
operation only.
3
