- Page 1 Eco P Series Lithium Battery Installation and Operation Manual Utilities and Residential Commercial Industrial Telecom Eco P Series Installation Manual Page V 2.0 +61 3 8797 5557 | info@powerplus-energy.com.au | Building 21-25, 885 Mountain Hwy, Bayswater Vic 3153 | powerplus-energy.com.au...
-
Page 2: Introduction
UPS, rectifiers, DC or AC coupled charging devices, on-grid and off-grid in single, dual or three phase applications. There is almost no limitations in applications and suitable devices that can charge or discharge the Eco P Series battery. Currently the Eco P Series battery is available in a 48V version. -
Page 3: Table Of Contents
PEW3 & PEW4 Installation PEF6W-250B Installation PEF9W-250 Installation Battery Operation and Commissioning Main Status LED Full Recharge Upon First Installation Trouble Shooting Maintenance Upgrading Battery Capacity Capacity Testing Battery End of Life Warranty Eco P Series Installation Manual Page V 2.0... -
Page 4: Safety
Installers and users are responsible for familiarising themselves with this manual. The Eco P Series batteries use a high grade cylindrical Lithium Ferro Phosphate (LFP) cells which are robust and reliable in higher ambient temperatures, have a long service life and with no heavy metals and are fully recyclable. -
Page 5: Damaged Battery
Damaged Battery A damaged battery should not be used and should be returned to the PowerPlus Energy or disposed of via a recycling facility. Leaking electrolyte can cause skin irruption and chemical burns so contact should be avoided. Eye Contact: Rinse gently with running water and seek medical attention if irritation develops. -
Page 6: Product Information
The technical information presented here within outlines the physical and electrical characteristics of the battery and what environment they should be installed in. Weight and Dimensions Eco4840P Depth 635mm Width 434mm Height 88mm Weight 43kg Eco P Series Installation Manual Page V 2.0... -
Page 7: Specifications
Greater than 10 years when used as per warranty terms Cooling Natural convection Parallel Stacking Unlimited - Refer Manufacturer Serial Stacking Alarm Output Normally closed, volt free, 1A maximum Certifications Pending IEC:62619:2017, UN38.3, EMC Eco P Series Installation Manual Page V 2.0... -
Page 8: Charging And Discharging
Refer relevant manual or cable sizing standard Refer Warranty document for warranty duration, installation, usage and Warranty maintenance requirements In our efforts towards constant product enhancement this specification is subject Note to change at anytime without notice Eco P Series Installation Manual Page V 2.0... -
Page 9: Charging Curves Eco 4840P
Charging Curves Eco 4840P Discharging Curves Eco 4840P Eco P Series Installation Manual Page V 2.0... -
Page 10: State Of Charge Vs Voltage
The below table can be used a guide for referencing voltage against energy in the battery. The below figures are taken at 25°C and with a 0.5C load applied. Eco4840P >53.00 100% 52.50 52.00 51.75 51.72 51.70 51.65 51.50 51.32 51.15 51.00 50.75 50.50 50.20 49.50 48.00 Eco P Series Installation Manual Page V 2.0... -
Page 11: Circuit Breaker Characteristic
Circuit Breaker Characteristic The integrated double pole DC is dual pole and a K curve type. The table below outlines the trip times based on current. Eco P Series Installation Manual Page V 2.0... -
Page 12: Installation
• And or, the battery system to be installed in a moisture and climate controlled room (example, reverse cycle cooled). • The temperature of the cabinet should be held at a temperature above dew point at all times. Eco P Series Installation Manual Page V 2.0... -
Page 13: Battery Installation
The battery has been designed to fit into a standard 800mm deep 9 inch rack enclosure. The enclosure should be fitted with PowerPlus Energy’s battery rails or similar to ensure stability and correct installation. Battery rails can be sourced from you normal PowerPlus Energy place of purchase. -
Page 14: Battery Connections
Battery Connections Each battery has a positive and negative Amphenol SurLok non keyed male connector for easy snap on connection. A range of cable and mating connectors are available from you normal PowerPlus Energy place of purchase. If multiple batteries are being used in parallel, the battery cables shall all be of the same length to retain equal impedance of each battery and cable set. -
Page 15: Case Earthing
The Eco battery has an M6 nut-set to allow case earthing should your application require grounding of case to the same potential across the application. A 5mm M6 bolts should be used. Eco P Series Installation Manual Page V 2.0... -
Page 16: Battery Alarm And Communication Installation
CABLE Battery daisy chain connector lead (30cm) COM0030A Battery Bridge connector COMLBA Battery Comms Cable (2Metre) COM020A Battery Comms Cable (5Metre) COM050A Battery Comms Cable (10Metre) COM100A Battery Comms Cable (15Metre) COM150A Eco P Series Installation Manual Page V 2.0... -
Page 17: Powerplus Energy Battery Enclosures
PowerPlus Energy Battery Enclosures PowerPlus Energy provides a range of mounting options to make your installation simple and easy. They have been design to suit indoor and outdoor applications and to secure a rage of different battery capacities. Rack Series Enclosures The Rack Series enclosure for domestic, commercial and utility installations, allows quick and easy visualisation of battery operation. -
Page 18: Rack Series Enclosure Installation
Note: When paralleling multiple battery cabinets, battery cables from each cabinet must be the same length and cable size to ensure cabinet impedances remain the same. The use of an external busbar is highly recommended. Eco P Series Installation Manual Page V 2.0... -
Page 19: Slimline Series Enclosures
SlimLine Series Enclosures PowerPlus Energy SlimLine series battery enclosures are designed to provide low profile options for mounting the LiFe and Eco batteries. Each style is available at 300 to 400mm deep making them suitable for installation in walkways, sides of buildings and alongside industrial equipment. -
Page 20: Pew3 & Pew4 Installation
Note: When paralleling multiple battery cabinets, battery cables from each cabinet must be the same length and cable size to ensure cabinet impedances remain the same. The use of an external busbar is highly recommended. Eco P Series Installation Manual Page V 2.0... -
Page 21: Pef6W-250B Installation
Note: Batteries should be loaded from the rear of the cabinet working your way to the front. This ensures the cabinet remains stable and weight is distributed closet to the wall. Supplied with PEF6. Eco P Series Installation Manual Page V 2.0... -
Page 22: Pef9W-250 Installation
finally the upper shelf. • Secure the busbar assembly back in to place. • Connect corresponding Amphenol cables to batteries. Eco P Series Installation Manual Page V 2.0... -
Page 23: Battery Operation And Commissioning
float stage. This fist initial charge will allow the battery BMS to perform a cell balance process and ensure all cells are at the same state before regular cycling. Eco P Series Installation Manual Page V 2.0... -
Page 24: Trouble Shooting
Upgrading Battery Capacity It is possible to add additional batteries to an existing Eco P Series installation at a later date. If you are to add extra capacity the battery must be of the same type, part number, and specification. -
Page 25: Capacity Testing Battery
= 92.5% End of Life When a PowerPlus Energy battery is removed from service it can be returned to PowerPlus Energy for recycling. Due to the stability and longevity of LFP cylindrical cells, returned batteries will be refurbished and checked so they can be repurposed for low power applications and made available for community, education and charity projects. -
Page 26: Warranty
Warranty PowerPlus Energy will protect this product under warranty when it is installed as written in this manual and used in the manner as set out in the warranty documents. Any product not being used or installed as outlined, will be in violation of the terms and will render the product void of any warranty.
