Models: LRS-2436B
(5301949)
(Steel Lawn Roller,
24" Diameter
& 36" Drum Length)
General Information
Thank you for purchasing this product. The purpose of this
manual is to assist you in operating and maintaining your
Lawn Roller assembly.
Retain a copy of your receipt for your unit,
as it will be required to validate any warranty service
Products are warranted against manufacturer or workmanship
defects for one year from date of purchase for home owner
usage and 90 days for commercial usage.
For technical assistance, visit our website @
www.fimcoindustries.com or call: TOLL FREE @ 1-800-831-0027
Our Technical Support Representatives will be happy to help you.
To obtain prompt, efficient service, always remember to give the
following information...
Correct Part Description and/or part number
Model #/Serial # of your sprayer
Part descriptions and numbers can be obtained from the illustrated
parts list section(s) of this manual.
OWNER'S MANUAL
Technical Specifications
(LRS-2436B = Boxed)
Roller Drum:
24", Heavy Gauge Welded Steel
Roller Head:
24" Precision Stamped and Welded Steel
Overall Width: 45" Wide
Weight Filled with Water: 716 lbs.
Assembled Weight Empty: 147 lbs.
Bearings: 3/4" I.D. Replaceable
Tow Hitch: STD. Type, 5/8" pin hole
Approximate Shipping Weight: 164 lbs. boxed
www.fimcoindustries.com
1000 FIMCO Lane, P.O. Box 1700, North Sioux City, SD 57049
Toll Free Phone: 800-831-0027 : Toll Free Fax: 800-494-0440
[5008296
(11/18)]
