Fimco LG-30-TRL Owner's Manual

Fimco LG-30-TRL Owner's Manual

30 gallon lawn & garden trailer sprayer 5302317
Hide thumbs Also See for LG-30-TRL:

Advertisement

General Information
Thank you for purchasing this product. The purpose of this
manual is to assist you in operating and maintaining your
lawn & garden/ATV sprayer. Please read it carefully, as it
furnishes information which will help you achieve years of
trouble-free operation.
Warranty
Products are warranted for one year from date of purchase against
manufacturer or workmanship defects for home owner usage and
90 days for commercial usage.
For technical assistance, visit our website @ www.fimcoindustries.com
or call: TOLL FREE @ 1-800-831-0027
Our Technical Support Representatives will be happy to help you.
To obtain prompt, efficient service, always remember to give the
following information...
Correct Part Description and/or part number
Model #/Serial # of your sprayer
Part descriptions and numbers can be obtained from the illustrated
parts list section(s) of this manual.
OWNER'S MANUAL
Model: LG-30-TRL (5302317)
(30 Gallon Lawn & Garden Trailer Sprayer)
Technical Specifications
30 Gal. Corrosion-Resistant Polyethylene Tank
12 Volt Diaphragm Pump, 2.1 g.p.m.—60 psi
15 Ft. Handgun Hose
25 Ft. max. vertical throw, 35 Ft. horizontal throw
Pressure Gauge (0-100 psi)
2-Nozzle Steel Boom Assembly
(80" Spray Coverage)
Corrosion-Resistant Nylon Nozzles
Bypass (recirculation) Line w/ON/OFF Control
Heavy Duty 16" tires
Easy access drainage port
Front forward gun and hose wrap for easier
access from transport vehicle
Complete drain out tank
Streamlined tank design for compact storage and shorter
turning radius.
Caution: Always check the vehicle load rating before
using the sprayer. The loaded weight of this sprayer
and boom assembly is approx.: 270 lbs. when the tank
is full.

Assembly Instructions

Make sure the contents of the sprayers carton match the
items shown on page 2 of the manual.
Follow the steps on pages 3 & 4 to properly assemble the
sprayer.
www.fimcoindustries.com
1000 FIMCO Lane, P.O. Box 1700, North Sioux City, SD 57049
Toll Free Phone: 800-831-0027 : Toll Free Fax: 800-494-0440
[5008450
226111
(02/15)]
Page 1
