Polygroup TG76P6059D02 Assembly Instructions

TREE ASSEMBLY INSTRUCTIONS
Congratulations on purchasing your new tree from
Carefully follow the instructions below on how to quickly and easily set up your new tree.
Fig. A - Tree and Light Assembly
Quick Fold
Quick Fold
Quick Fold TM Cinch
• Before you start to assemble your tree, choose an appropriate location near a wall outlet.
• Assemble the tree stand and place on a level surface. (See Fig. B)
Fig. B - Tree Stand Assembly
SET UP INSTRUCTIONS WITH QUICK FOLD
1
Section 2
Section 1
Section 3
Tree stand
Each tree section is numbered
with a tag. Please identify all
sections before assembling.
MODEL #: TG76P6059D02
Polygroup®!
3
TM Cinch
TM Cinch
2
1
Click
2
Section 1
Tree stand
Insert Section 1 into the tree stand.
*Electrical Rating For The Tree
(For Indoor Use Only)
Input:120VAC, 60Hz, 0.25A Max.
Output: 29V DC 0.45A
Do Not Tamper
Internal Parts
Quick Set®
Connections
Open the
protective
cover
Quick Set®
Connections
Insert Green
Control box
Label Extension
Cord into Adaptor
Pull apart the legs of the stand so that they
are snapped into an x-shape, place the tree
stand on a level surface.
To close the stand, press the metal button
and fold the legs together.
TM
3
A
Cinch
Handle
Cinch Clip B
C
A. Locate "Pull Here" tab and corresponding
Cinch Handle
B. Hold Cinch Clip firmly with one hand and
press down on clip
C. With Cinch Clip depressed, pull clip away from
tree until all branches are released.
Do Not Tamper
Internal Parts
Open the
protective
cover
Adaptor
To Be Plugged
Into Wall
Outlet
