ENGINEERING COMPANY INC.
51 Winthrop Road
Chester, Connecticut 06412-0684
Phone: (860) 526-9504
Internet: www.whelen.com
Sales e-mail: autosale@whelen.com
Customer Service e-mail: custserv@whelen.com
Whelen's emergency vehicle warning devices must be properly mounted and wired in order to be effective and safe. Read and follow all of Whelen's written
instructions when installing or using this device. Emergency vehicles are often operated under high speed stressful conditions which must be accounted for
when installing all emergency warning devices. Controls should be placed within convenient reach of the operator so that they can operate the system without
taking their eyes off the roadway. Emergency warning devices can require high electrical voltages and/or currents. Properly protect and use caution around
live electrical connections.Grounding or shorting of electrical connections can cause high current arcing, which can cause personal injury and/or vehicle
damage, including fire. Many electronic devices used in emergency vehicles can create or be affected by electromagnetic interference. Therefore, after
installation of any electronic device it is necessary to test all electronic equipment simultaneously to insure that they operate free of interference from other
components within the vehicle. Never power emergency warning equipment from the same circuit or share the same grounding circuit with radio
communication equipment. All devices should be mounted in accordance with the manufacturer's instructions and securely fastened to vehicle elements of
sufficient strength to withstand the forces applied to the device. Driver and/or passenger air bags (SRS) will affect the way equipment should be mounted. This
device should be mounted by permanent installation and within the zones specified by the vehicle manufacturer, if any. Any device mounted in the deployment
area of an air bag will damage or reduce the effectiveness of the air bag and may damage or dislodge the device. Installer must be sure that this device, its
mounting hardware and electrical supply wiring does not interfere with the air bag or the SRS wiring or sensors. Mounting the unit inside the vehicle by a
method other than permanent installation is not recommended as unit may become dislodged during swerving; sudden braking or collision. Failure to follow
instructions can result in personal injury. Whelen assumes no liability for any loss resulting from the use of this warning device. PROPER INSTALLATION
COMBINED WITH OPERATOR TRAINING IN THE PROPER USE OF EMERGENCY WARNING DEVICES IS ESSENTIAL TO INSURE THE SAFETY OF
EMERGENCY PERSONNEL AND THE PUBLIC.
Whelen's emergency vehicle warning devices are intended to alert other operators and pedestrians to the presence and operation of emergency vehicles and
personnel.
However, the use of this or any other Whelen emergency warning device does not guarantee that you will have the right-of-way or that other
drivers and pedestrians will properly heed an emergency warning signal. Never assume you have the right-of-way. It is your responsibility to proceed safely
before entering an intersection, driving against traffic, responding at a high rate of speed, or walking on or around traffic lanes. Emergency vehicle warning
devices should be tested on a daily basis to ensure that they operate properly. When in actual use, the operator must ensure that both visual and audible
warnings are not blocked by vehicle components (i.e.: open trunks or compartment doors), people, vehicles, or other obstructions. It is the user's responsibility
to understand and obey all laws regarding emergency warning devices. The user should be familiar with all applicable laws and regulations prior to the use of
any emergency vehicle warning device. Whelen's audible warning devices are designed to project sound in a forward direction away from the vehicle
occupants. However, because sustained periodic exposure to loud sounds can cause hearing loss, all audible warning devices should be installed and
operated in accordance with the standards established by the National Fire Protection Association.
Safety First
This document provides all the necessary information to allow your Whelen product to be properly and safely installed. Before beginning the installation and/or
operation of your new product, the installation technician and operator must read this manual completely. Important information is contained herein that could
prevent serious injury or damage.
WARNING: This product can expose you to chemicals including Methylene Chloride which is known to the State of California to cause cancer, and
Bisphenol A, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to
www.P65Warnings.ca.gov.
Proper installation of this product requires the installer to have a good understanding of automotive electronics, systems and procedures.
Whelen Engineering requires the use of waterproof butt splices and/or connectors if that connector could be exposed to moisture.
Any holes, either created or utilized by this product, should be made both air- and watertight using a sealant recommended by your vehicle
manufacturer.
Failure to use specified installation parts and/or hardware will void the product warranty.
If mounting this product requires drilling holes, the installer MUST be sure that no vehicle components or other vital parts could be damaged
by the drilling process. Check both sides of the mounting surface before drilling begins. Also de-burr the holes and remove any metal shards
or remnants. Install grommets into all wire passage holes.
If this manual states that this product may be mounted with suction cups, magnets, tape or Velcro®, clean the mounting surface with a 50/50
mix of isopropyl alcohol and water and dry thoroughly.
Do not install this product or route any wires in the deployment area of your air bag. Equipment mounted or located in the air bag deployment
area will damage or reduce the effectiveness of the air bag, or become a projectile that could cause serious personal injury or death. Refer to
your vehicle owner's manual for the air bag deployment area. The User/Installer assumes full responsibility to determine proper mounting
location, based on providing ultimate safety to all passengers inside the vehicle.
For this product to operate at optimum efficiency, a good electrical connection to chassis ground must be made. The recommended
procedure requires the product ground wire to be connected directly to the NEGATIVE (-) battery post (this does not include products that use
cigar power cords).
If this product uses a remote device for activation or control, make sure that this device is located in an area that allows both the vehicle and
the device to be operated safely in any driving condition.
Do not attempt to activate or control this device in a hazardous driving situation.
This product contains either strobe light(s), halogen light(s), high-intensity LEDs or a combination of these lights. Do not stare directly into
these lights. Momentary blindness and/or eye damage could result.
Use only soap and water to clean the outer lens. Use of other chemicals could result in premature lens cracking (crazing) and discoloration.
Lenses in this condition have significantly reduced effectiveness and should be replaced immediately. Inspect and operate this product
regularly to confirm its proper operation and mounting condition. Do not use a pressure washer to clean this product.
It is recommended that these instructions be stored in a safe place and referred to when performing maintenance and/or reinstallation of this
product.
FAILURE TO FOLLOW THESE SAFETY PRECAUTIONS AND INSTRUCTIONS COULD RESULT IN DAMAGE TO THE PRODUCT OR VEHICLE
AND/OR SERIOUS INJURY TO YOU AND YOUR PASSENGERS!
©1994 Whelen Engineering Company Inc.
Form No.13031F (020607)
®
Warnings to Installers
Warnings to Users
For warranty information regarding this product, visit www.whelen.com/warranty
Page 1
Installation/Wiring Guide:
DOT3® System 104/204

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DOT3 System 104 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Whelen Engineering Company DOT3 System 104 Series

  • Page 1 FAILURE TO FOLLOW THESE SAFETY PRECAUTIONS AND INSTRUCTIONS COULD RESULT IN DAMAGE TO THE PRODUCT OR VEHICLE AND/OR SERIOUS INJURY TO YOU AND YOUR PASSENGERS! ©1994 Whelen Engineering Company Inc. For warranty information regarding this product, visit www.whelen.com/warranty Form No.13031F (020607)
  • Page 2 WARNING! DISCONNECTING VEHICLE BRAKE LAMP CIRCUIT USING ANY SIRENS WITH RELAY OUTPUTS SWITCH CONTROLLERS COULD CAUSE VEHICLE OR PROPERTY DAMAGE, SERIOUS INJURY OR EVEN DEATH. DISABLING THIS CIRCUIT IS A VIOLATION OF THE FEDERAL MOTOR VEHICLE SAFETY STANDARD FOR THE THIRD BRAKE LIGHT, AS WELL AS REAR BRAKE LIGHTS.
  • Page 3: Table Of Contents

    Table Of Contents Introduction ........................page 4 Parts List .......................... page 4 Mounting the ISP94 Power Supply .................. page 5 Wiring the ISP94 Power Supply ..................page 6 Mounting the Remote Head Assembly................page 6 Wiring the Remote Head Assembly ................. page 6 Systems 104-A and 204-A ..................
  • Page 4: Introduction

    Introduction... The material contained in this manual provides the information necessary for proper installation of Whelen ® Engineering’s DOT3 Lighting System. This includes all wiring and mounting information for models 104 & ® 204. However, because the DOT3 System is designed to be versatile enough to meet any and all needs, customized system configurations are common.
  • Page 5: Mounting The Isp94 Power Supply

    System 204-D Description Qty. Part Number DOT 9 Connector Flex Tube Kit (Contains 2 Assemblies) 01-0416222-00 DOT 9 Connector Cable Kit (DOT Harness Kit Included, Qty. 2) 1 01-0462508-00 Model DOT-52 “D” Remote Head 01-0683625AX3 ISP94 Intelligent Strobe Power Supply, w/Diagnostix™ 01-0668156-00 9 Connector DOT Waterproof Cable (Driver Side/30 Foot) 02-0262508-00...
  • Page 6: Wiring The Isp94 Power Supply

    Wiring the ISP94 Power Supply... Locate the 4 position, pin housing that contains two RED wires and two BLACK wires. Extend these wires (using customer supplied in- line splices) towards the vehicle’s battery. Connect the spliced, BLACK wires to the factory chassis ground adjacent to the battery. The spliced RED wires must be connected to a user supplied, 30 amp fuse and then to the battery’s POSITIVE (+) terminal.
  • Page 7: Systems 104-B And 204-B

    Fig.1 Cable Locking Clamp Fixture Locking Locking Cuff Primary Flex Tube Shaft Housing Driver Side ...Connect to OUTLET 1 on the front of the ISP94 power supply Passenger Side ...Connect to OUTLET 3 on the front of the ISP94 power supply SYSTEMS 104-B &...
  • Page 8: Flex Tube Housing Assembly

    YELLOW wire Driver Side Tail Light (Positive) BLUE wire Negative Ground VIOLET wire Driver Side Brake Light and Left Turn Signal Light (Positive) BROWN wire Negative Ground GREEN wire Back Up Light (Positive) ORANGE wire Auxiliary Wire Passenger Side/End of cable towards Remote Head RED wire Position A in the 3 position DEUTSCH connector BLACK wire...
  • Page 9: Systems 104-D, 104-H Or 204-D

    SYSTEMS 104-D, 104-H & 204-D Driver Side/End of cable towards Remote Head RED wire Position A in the 3 position DEUTSCH connector BLACK wire Position B in the 3 position DEUTSCH connector WHITE wire Position C in the 3 position DEUTSCH connector Connect to Strobe Light in Remote Head.
  • Page 10: Mounting & Wiring The Dual Switch Assembly

    Passenger Side/End of cable towards Power Supply RED wire Connect (with Set Screw Connectors) to RED wire on Harness Kit Insert other end of RED Harness Kit wire into Position 1 on connector. BLACK wire Connect (with Set Screw Connectors) to BLACK wire on Harness Kit Insert other end of BLACK Harness Kit wire into Position 2 on connector.
  • Page 11: System Illustrations 104-A And 204-A

    Page 11...
  • Page 12: 104-B And 204-B

    Page 12...
  • Page 13: 104-D, 104-H And 204-D

    Page 13...
  • Page 14: Isp94 Mounting Template

    DRILLING TEMPLATE FOR ISP94 POWER SUPPLY 6.25" 0.218" (7/32") dia. IMPORTANT NOTE!! The template(s) included with this manual MAY NOT BE TO SCALE. CONFIRM ALL DIMENSIONS. Before drilling, POWER SUPPLY OUTLINE Page 14...
