Burn Bright with Orion
SPARE PARTS
SEVERN
4kW / 5kW / 8kW
installation & operating manual
CO
0.10
0.12
0.10
%
0.12%
%
%
NOx
ECO
DESIGN
CxHy
READY
TO BE INSTALLED BY A HETAS QUALIFIED INSTALLER
Henley Stoves cannot accept responsibility for any fault or
consequential problems arising through incorrect installation or operation.
Advertisement
Table of Contents
Related Manuals for Henley Stoves Orion SEVERN Series
Summary of Contents for Henley Stoves Orion SEVERN Series
- Page 1 4kW / 5kW / 8kW installation & operating manual 0.10 0.12 0.10 0.12% DESIGN CxHy READY TO BE INSTALLED BY A HETAS QUALIFIED INSTALLER Henley Stoves cannot accept responsibility for any fault or consequential problems arising through incorrect installation or operation.
- Page 2 Congratulations on the choice of your New Henley-Orion Stove! With the proper care & attention your Henley-Orion stove will give you a lifetime of heat & comfort. This manual contains instructions on how to install and maintain your Henley-Orion Stove. For both your comfort &...
-
Page 3: Table Of Contents
Technical Information Installation Instructions Hearth Ventilation Chimney Flue Positions Height Over Adjacent Building Height Over Roof Height Over Openings Flue Options Flue Options - Top/Rear Flue Options - Diagram Non-Combustible Materials External Air The Clean Air Act 1993 Combustible Materials Recommended Fuels Lighting The Stove Re-fueling... - Page 4 SEVERN 4kW SEVERN 5kW SEVERN 8kW CONFIRMS TO : EN13240 SEVERN Wood Wood Wood Nominal Heat Output kW 4.1kW 5.0kW 8.4kW Weights + Logstores 53KG - 63KG 59KG - 71KG 78KG - 95KG Total Efficiency % 75.4% 75.6% 79.0% ERP Energy Rating Mean CO (at 13 % O2) 0.10 0.12...
- Page 5 4kW w/ LOGSTORE Fixing the Logstore 5kW w/ LOGSTORE 8kW w/ LOGSTORE Fixing the optional logstore to your Stove, Please find included with logstore the 4 fixing bolts required. These must be secure for stove to savely be used with logstore option.
-
Page 6: Installation Instructions
installation instructions Fire Cement Some types of fire cement are caustic and Before installation and/or use of this appliance should not be allowed to come into contact please read these instructions carefully to ensure with the skin. In case of skin contact, wash that all requirements are fully understood. -
Page 7: Hearth
hearth The Stove should be installed on: Hearths should be constructed from suitably Hearths made of non-combustible board / robust materials & to appropriate dimensions. sheet material or tiles at least 12mm thick A way of making provision would be to adopt the (fig.2) if the appliance is not to stand in an appliance guidelines outlined below &... -
Page 8: Ventilation
ventilation The following must be checked: • The construction of the masonry chimneys, This appliance requires a constant supply of air flue block chimneys & connecting flue pipe to maintain proper combustion and effective flue system must meet requirements of the Building performance. -
Page 9: Chimney
chimney Suitable access must be provided to enable the collection and removal of debris. The flue must be swept and inspected when the appliance is installed. WARNING Under no circumstances should The flue draught must be checked with all this appliance be connected to windows and doors closed and any extraction a shared flue system, that serves fans in this, or adjoining rooms, running at... -
Page 10: Height Over Adjacent Building
Height Over Adjacent Building The Outlet of a chimney or flue in relation to an adjacent building should be as seen above Height Over Roof Outlet of a chimney or a flue to be not less that 1m above the highest point of contact of chimney and roof. Where the roof has a pitch of more than 10º... -
Page 11: Flue Options
flue options Each installation is unique to the property so it is WARNING not possible to give details to suit every setting. If Not using External Air Supply The installation must comply with Building Do not remove cover from back of outlet. -
Page 12: Non-Combustible Materials
non-combustible materials external air The external air supply allows the stove to be installed in a room that may otherwise be sealed to an extent that would prohibit the correct and safe burning of a wood stove. This would also apply to new builds in general which are sealed to a very high level to meet various energy efficiency targets. -
Page 13: The Clean Air Act 1993
combustiible materials The Clean Air Act 1993 & Safe distances to combustible materials for the Smoke Control Areas Severn 4kW & 5kW: should be 600mm Back and 500mm to the sides, Severn 8kW should be 750mm Back and Under the Clean Air Act local authorities may 500mm to the sides. -
Page 14: Lighting The Stove
Once the ignition period is well under way close the primary air gradually to establish the burning DO NOT BURN intensity you require (usually open 25% approx.). bituminous coal,‘petro-coke’ or other petroleum based fuels as this will invalidate the product warranty. refueling the stove When burning wood logs it is recommended to When burning wood, the fire will die down as the... -
Page 15: Refueling On To A Low Fire Bed
shuting down stove The stove will normally shut down by itself as the When refueling the appliance fuel is consumed. it was necessary to leave the door ajar for a period of 1 - 2 minutes in order to sustain In order to shut down the stove for other flames on the newly charged fuel load. - Page 16 removing fire rope This should be done by and competent person such as a NACS chimney engineer who will provide a Certificate of Chimney Sweeping. Periodically visually check over the door rope seal for any damage, cuts or tears and detached Sweep the whole flue way, including the outlet at sections.
-
Page 17: Baffle Plate
replacing baffle • Replace the rope gasket, remove the self adhesive backing on the rope as you go, start at the bottom of the window, centrally. Push the adhesive side of the rope into the grove on the rear of the door casting gradually work your way round until the ends of the rope meet. -
Page 18: Air Controls
Henley Stoves appliances have air systems providing cleaner burning, and greater efficiency and control. Please see diagram to view where close the various air controls are located on your Henley Stove 1) Primary Air - Pulling out right lever on bottom... -
Page 19: Stove Finish (Paint)
stove finish - paint chimney fire & over heating The outside of the stove is finished in a durable DO NOT OVER FIRE YOUR APPLIANCE. high temperature paint. Over firing your stove will cause the paint to peel off your stove and is not covered in our warranty. It is best cleaned by brushing down with a soft brush. -
Page 20: Spare Parts
spare parts Over time you may require replacement parts for your Stove. Replacement parts are available through your local stockist. Please use the below diagram to establish the part you require for your stove. Please ensure you quote model name and also serial number of stove when ordering spare parts. ONLY USE GENUINE Henley-Orion APPROVED REPLACEMENT PARTS FOR YOUR STOVE. -
Page 21: Faq's
Why is there no heat from my stove? faq’s 1) If your stove is installed in an alcove, you need to cap off the area directly above the Why are my air inlets puffing smoke? stove by installing a 3mm mild steel plinth with Combustion gases can build up in the firebox insulation to prevent the heat from escaping. -
Page 22: Annual Service
seasonal use My grate has already burned out, why is this? 1) Not cleaning the grate after every fire will result Remove the baffle and inspect the inside of in the grate burning out prematurely. the stove and the flue ways and ensure they are 100% clear after a period of disuse, for How often should I clean my chimney? example if the stove is not used during the... -
Page 23: Terms & Conditions
terms & conditions You need to register your warranty online or via the post in order to activate the warranty for http://service.henleystoves.com/ your stove. Failing to register your stove will only give you standard Warranty. Warranty Terms & Conditions 3 Year Warranty 1 year standard manufacturers warranty as in accordance with EU regulations. - Page 24 & conditions Replacement Parts • Replacement parts are available through Henley Stoves Services. • Please contact us directly in order to clearly identify the replacement part you require. Maintenance • Neglecting to regularly service your Stove or maintain it to an acceptable standard IE if parts are clearly damaged, burnt out &...
-
Page 26: Stove Commissioning Checklist
Stove Commissioning Checklist Please complete the form below as it will be of great assistance in the highly unlikely event that there is a problem with the stove or a warranty claim needs to be made. Please contact the person who installed the stove or the dealer where it was purchased from if there is a problem. - Page 27 All warranty claims will only be entertained when the Online Warranty Form is http://service.henleystoves.com/ completed, this can be found at It should be completed correctly and submitted with a photo or scan of the original dated proof of purchase. Otherwise you can fill in below details along with a photo or scan of the original dated proof of purchase and mail these to: Henley-Orion Service Dept., Half Acre Ind.
- Page 28 www.henleystoves.com...
