Summary of Contents for Aiwa HS-TA166 YL
- Page 1 HS-TA166 SERVICE MANUAL STEREO RADIO BASIC TAPE MECHANISM : 4ZM-2 P13NC2 CASSETTE PLAYER S/M Code No. 09-99B-406-0R3...
-
Page 2: Specifications
SPECIFICATIONS Frequency range: FM: 87.5 – 108 MHz AM: 530 – 1710 kHz Maximum output: 15 mW + 15 mW (EIAJ/32 ohms) Power source: DC 3V using two R6 (size AA) batteries Maximum dimensions: 92.0 (W) x 116.4 (H) x 38.3 (D) mm in.) Weight: Approx.131.5 g (4.6 oz) (excluding batteries) -
Page 3: Electrical Main Parts List
ELECTRICAL MAIN PARTS LIST TRANSISTOR ILLUSTRATION REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 87-A11-726-080 C-CAP,S 0.33-16 Z F 87-A11-733-080 C-CAP,S 1-16 Z F 87-A21-387-040 C-IC,TA2145F C105... - Page 4 WIRING...
-
Page 5: Schematic Diagram
SCHEMATIC DIAGRAM... -
Page 6: Mechanical Exploded View
ADJUSTMENT MECHANICAL EXPLODED VIEW 1 /1 A MAIN C.B VOLUME L104 PVC101 PVC1 L102 TC101 TC104 TC102 L103 SFR51 TC103 SFR 1 L105 PHONES P HEAD L101 BAR ANT <TUNER SECTION> <TAPE PLAYER SECTION> 1. AM IF Adjustment 6. Tape Speed Adjustment L105 ............... -
Page 7: Mechanical Parts List
MECHANICAL PARTS LIST 1/1 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 1 8Z-HRM-103-010 WINDOW,CASS SIL 166YL 2 8Z-HRM-101-010 LID,CASS SIL 166YL 3 86-HRM-205-010 SPR-T,CLICK 4 81-HK9-208-210 SPR-P,CASS A 5 87-HRR-206-010 PLATE,HEAD J034 6 88-HRJ-038-010 FRAME,CENTRE J034 7 86-HRM-009-110 POINTER,TUN 8 86-HRM-006-010... -
Page 8: Tape Mechanism Exploded View
TAPE MECHANISM EXPLODED VIEW 1/1 REEL TABLE,L FRAME,CENTER SHAFT,REEL FELT,CLUTCH LEVER,REW G CAPSTAN, 1.8-23.3... - Page 9 TAE MECHANISM PARTS LIST 1/1 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 84-ZM2-012-110 LEVER,PLAY G 84-ZM2-211-110 GEAR,CONNECT 84-ZM2-222-110 SPR-T,PLAY 84-ZM2-015-110 LEVER,STOP G 84-ZM2-216-210 REEL TABLE,R 84-ZM2-013-110 LEVER,FF G 84-ZM2-223-110 SPR-T,REW STOP 84-ZM2-232-310 BELT,MAIN 84-ZM2-221-110 FLY-WHL,P2 84-ZM2-228-310 SPR-C,BT 84-ZM2-220-110...
- Page 10 2-11, IKENOHATA 1-CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 9630469 9630472 0251431 Printed in Singapore...
