- Page 1 HS-TA164 YJ1,YH1,YVJ1 SERVICE MANUAL STEREO RADIO BASIC TAPE MECHANISM : 4ZM-2 P3N,P6N CASSETTE PLAYER S/M Code No. 09-992-406-0R2...
-
Page 2: Specifications
15 mW + 15 mW (EIAJ/32 ohms) Power source: DC 3V using two R6 (size AA) batteries AC house current using the optional AC adaptor AIWA AC-D302<YH1 only> Battery life: (EIAJ 1mW playback): Approx. 5.5 hours using R6P (size AA) manganese batteries Approx. -
Page 3: Transistor Illustration
ELECTRCAL MAIN PARTS LIST REF. NO. PART NO. KANRI DESCRI P TI O N REF. NO. PART NO. KANRI DESCRI P TI O N REF. NO. PART NO. KANRI DESCRI P TI O N REF. NO. PART NO. KANRI DESCRI P TI O N CHIP RESISTOR PART CODE Chip Resistor Part Coding C113... -
Page 5: Schematic Diagram
SCHEMATIC DIAGRAM... - Page 6 <TUNER SECTION> <TAPE SECTION> A MAIN C.B <FM SECTION> Tape speed : 3000Hz ± 60Hz Sensitivity : Wow & flutter : Less than 0.50% (RMS) (IHF, THD 3%) Less than 17dB Take-up torque : 35 ~ 50 g-cm (FWD, REV) [at 88/98MHz<YH1,YJ1>] F.F torque : More than 36 g-cm...
- Page 9 8Z-HRM-050-010 WINDOW,CASS BLU YV<YVJ1> 8Z-HRM-048-010 WINDOW,CASS BLU YZ<YH1,[S]YJ1> 8Z-HRM-003-010 WINDOW,CASS YZ<[LT]YJ1,[LL]YJ1> 8Z-HRM-009-210 LID,CASS SIL<[S]YJ1,YH1,YVJ1> 8Z-HRM-029-110 LID,CASS LBLU<[LL]YJ1> 8Z-HRM-035-110 LID,CASS TBLU<[LT]YJ1 86-HRM-205-010 SPR-T,CLICK 81-HK9-208-210 SPR-P,CASS A 87-HRR-206-010 PLATE,HEAD J034<[S]YJ1,YH1,YVJ1> 8Z-HRM-201-010 PLATE,HEAD TBLU<[LT]YJ1> 88-HKB-205-010 PLATE,HEAD VIO<[LL]YJ1> 8Z-HRM-044-010 FRAME,CENTER TBLU<[LT]YJ1> 88-HKB-043-010 FRAME,CENTER J034<[S]YJ1,YH1,YVJ1> 88-HKA-027-010 FRAME,CENTER VIO<[LL]YJ1>...
- Page 10 FRAME,CENTER...
- Page 11 84-ZM2-012-010 LEVER,PLAY G 84-ZM2-211-01K GEAR,CONNECT 84-ZM2-222-010 SPR-T,PLAY 84-ZM2-015-010 LEVER,STOP G 84-ZM2-014-010 LEVER,REW G 84-ZM2-013-010 LEVER,FF G 84-ZM2-223-010 SPR-T,REW STOP 84-ZM2-232-010 BELT,MAIN 84-ZM2-221-010 FLY-WHL,P2 84-ZM2-230-010 CAPSTAN,P 1.8-25 84-ZM2-220-01K BRG,P 84-ZM2-210-01K GEAR,AUTO 84-ZM2-218-01K CAP,GEAR AUTO 84-ZM2-208-01K LEVER,SHIFT 84-ZM2-224-010 SPR-T,FF LOCK 84-ZM2-207-01K LEVER,AUTO 84-ZM2-206-01K LEVER,LOCK 84-ZM2-219-01K...
- Page 12 FRAME,CENTER SHAFT REEL FELT,CLUTCH CAPSTAN,1.8-23.3...
-
Page 13: Lever,Lock
84-ZM2-244-010 BELT,MAIN Y 84-ZM2-220-110 BRG,P 84-ZM2-211-010 GEAR,CONNECT 84-ZM2-216-210 REEL TABLE,R 84-ZM2-223-110 SPR-T,REW STOP 84-ZM2-034-010 LEVER,REW W 84-ZM2-224-110 SPR-T,FF LOCK 84-ZM2-033-010 LEVER,FF W 84-ZM2-207-310 LEVER,AUTO 84-ZM2-035-010 LEVER,STOP W 84-ZM2-206-410 LEVER,LOCK 84-ZM2-222-110 SPR-T,PLAY 84-ZM2-228-210 SPR-C,BT 84-ZM2-221-110 FLY-WHL,P2 84-ZM2-208-310 LEVER,SHIFT 84-ZM2-210-210 GEAR,AUTO 84-ZM2-218-110 CAP,GEAR AUTO 84-ZM2-225-010 SPR-T,AUTO... - Page 14 84-ZM2-225-010 84-ZM2-226-010 SPR-T,AUTO FIND SPR-C,CLUTCH 84-ZM2-228-010 SPR-C,BT 84-ZM2-224-010 SPR-T,FF LOCK 84-ZM2-222-010 SPR-T,PLAY 84-ZM2-227-010 84-ZM2-223-010 SPR-C,AZIMUTH SPR-T,REW STOP...
- Page 15 84-ZM2-225-010 84-ZM2-226-510 SPR-T,AUTO FIND SPR-C,CLUTCH 84-ZM2-228-210 SPR-C,BT 84-ZM2-224-110 SPR-T,FF LOCK 84-ZM2-222-110 SPR-T,PLAY 84-ZM2-227-310 84-ZM2-223-110 SPR-C,AZIMUTH SPR-T,REW STOP...
