IMP OR T AN T D OC U ME N T – P LE AS E R E TAIN !

Activation process

Before using the LEUCHTIE for the first time please remove the transport protection (insulation cap).
It is the red stopper located at the opposite side of the size sticker.
Opening:
1.
Separate the tube from the battery
pack by pulling them apart with a slight
angular movement, taking care not to
use excessive force (1).
In doing so, hold the silicone sleeve
onto the battery compartment.
2.
Remove the red insulation cap (2)
and discard.
Fix the attachment loop:
3.
In order to secure the LEUCHTIE to
a collar or harness with the enclosed
fixation loop, pull the open end of the
tube through both transparent rubber
rings of the loop (3).
Closing:
4.
Insert both ends of the tube one after
the other straight into the battery com-
partment. Be careful not to bend the
contact springs.
5.
Press the battery pack and the tube
firmly together on both sides as far
as it can go, until they are closed
properly.
IMPORTANT: There must be no gap
between the battery pack and the tube
(see also figures page 3).
Instruction
®
LEUCHTIE
for alkaline batteries type AAA/micro
Manual
Plus
Effective 08/2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Plus and is the answer not in the manual?

Questions and answers

Summary of Contents for Leuchtie Plus

  • Page 1 Plus for alkaline batteries type AAA/micro Activation process Before using the LEUCHTIE for the first time please remove the transport protection (insulation cap). It is the red stopper located at the opposite side of the size sticker. Opening: Separate the tube from the battery...
  • Page 2 Replace both batteries immediately if the brightness of the LEDs decreases significantly or if the LEUCHTIE turns off shortly after switching on. Change the batteries in a dry and clean place and make sure that both the LEUCHTIE and your hands are dry and free of grease.
  • Page 3 The silicone sleeves are located on both sides centrally on the transition from battery part to light tube and do not show any defects. The LEUCHTIE is completely closed up to the stop: there is no gap between the light tube and the battery compartment.
  • Page 4 Spare parts & repair service If required, you can obtain rechargeable batteries, inexpensive spare parts and useful accessories from www.shop.leuchtie.com your dealer or directly from us: If, contrary to expectations, a case of damage occurs which you or your dealer cannot repair, we offer you the possibility of an uncomplicated repair at any time: www.leuchtie.de/service...
  • Page 5 Please use the LEUCHTIE only for its designated purpose. • Do not attach a lead to the LEUCHTIE and avoid holding your dog by the LEUCHTIE. Too much force on the LEUCHTIE could cause the batteries and other parts to fall out and get lost.
  • Page 6 Disposal / Recycling / Labeling This product meets the requirements of the Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of hazardous substances in electrical and electronic equipment. Please protect the environment and recycle this product.
