Summary of Contents for UWE AQM Series
-
Page 2: Table Of Contents
CONTENTS CAUTIONS 1. INSTALLATION 2. SPECIFICATIONS 3. KEYBOARD LAYOUT AND DESCRIPTION 4. INITIAL SETUP 5. INSTRUCTION FOR USE 6. TROUBLE SHOOTING 7. DAILY CARE AND MAINTENANCE... - Page 3 CAUTIONS 1. This unit is legal for trade only when it is sealed (and/or stamped) and bearing a serial number. Do not attempt to break the seal (or stamp) affixed to this scale or remove the serial number. Contact your dealer for more information and after sales service.
-
Page 4: Installation
1. INSTALLATION Check and make sure that the following accessories are included: Operation Manual x 1 Scale x 1 Plastic platter x 1 Stainless steel cover x 1 (Optional) Power adaptor x 1 Contact your dealer if any item is missing. Place the stainless steel platter (if purchased) onto the plastic platter. -
Page 5: Specifications
2. SPECIFICATIONS Model No. Capacity Division (e) (Max) OIML Extended AQM-1500 1500g 0.5g 0.05g AQM-3000 3000g 0.1g AQM-6000 6000g 0.2g Tare Range Full Tare Range Power-on ±10% Max Zero Range Zero Range ±2% Max Min. Load Power By Built-in Rechargeable Battery or AD/DC Source Power Adaptor Operating... -
Page 6: Keyboard Layout And Description
3. KEYBOARD LAYOUT AND DESCRIPTION OFF KEY Press this key to turn scale off ON/ZERO KEY Press this key to turn scale on or set weight to zero MODE KEY Press this key to shift among different weight units and/or turn backlight on/off TARE KEY Press this key to tare off the weight of a container. - Page 7 METRIC UNIT INDICATOR This indicator appears to indicate the weighing unit currently engaged is in metric (gram) AVOIRDUPOIS UNIT INDICATOR This indicator appears to indicate the weight unit currently engaged is in avoirdupois (pound/ounce, e.g. 2.15.1 means 2 lb and 15.1 ounce). ZERO INDICATOR This indicator appears to indicate a zero weight status NET INDICATOR...
-
Page 8: Initial Setup
4. INITIAL SETUP 4.1 PLACING THE SCALE In order to obtain an accurate weighing result, the scale must be placed on a strong and level surface. If required, adjust the adjustable feet underneath scale to obtain a level position. Refer to the bubble indicator for leveling condition. - Page 9 The scale is equipped with Auto Power Off Function. The scale will power off automatically if it is not used for 4 minutes. Follow the below steps to enable/disable Auto Power Off Function. Scale is off Press and hold TARE, then press ON/ZERO Scale displays F.1 Press TARE three times Scale displays F.4...
- Page 10 Scale displays F.1 Press TARE six times Scale displays F.9 Press MODE to select between “Tr_on” or “TroFF” -To enable Auto Tare Function, press TARE when Tr_on appears -To disable Auto Tare Function, press TARE when TroFF appears Press ON/ZERO to confirm and restart the scale or TARE for next function setup...
-
Page 11: Instruction For Use
5. INSTRUCTION FOR USE 5.1 BEFORE WEIGHING Make sure that: The plastic platter is inserted firmly and the stainless steel platter cover is placed on the plastic platter. The scale is placed on a level and strong surface. The scale is turned on. The ZERO INDICATOR is on. - Page 12 5.3 SELECT WEIGHT UNIT Press MODE to shift between metric or avoirdupois weight units. The weight unit used before power off would be employed when the scale is turned on again. NOTE: To comply with the law of certain countries and certain approval requirements, the avoirdupois weight units may be disabled.
- Page 13 NOTE: -User only needs to press ON/ZERO once when setting the value to zero. The re-zero command will be memorized and take place when reading is stabled 5.6 TARE OFF THE WEIGHT OF A CONTAINER When a container is used, follow the below steps to manually tare off the weight of container and get the net weight.
- Page 14 5.7 CLEAR THE TARE FUNCTION Remove all loads from platter The tare effect will be cancelled: -Automatically if automatic tare function is employed, or -By pressing TARE After TARE is pressed, the NET INDICATOR would disappear. 5.8 EXTENDED DISPLAY This scale is equipped with extended display function for reference purpose only.
-
Page 15: Trouble Shooting
6. TROUBLE SHOOTING Syndrome Scale cannot be turned on Check: Is the scale charged? Action: Recharge the scale for at least 8 hours before first time use or plug in the power adaptor before power on the scale. Check Is the power adaptor inserted properly into both the electricity outlet and the DC inlet of scale. - Page 16 Syndrome Rated capacity cannot be reached Check Is the NET INDICATOR on? Action: Turn the scale off. Remove all loads from platter and turn on again. Check Is there anything obstructing the platter? Action Remove all obstacles. Syndrome Weighing result is not accurate Check Is the scale placed in a level condition? Action...
-
Page 17: Daily Care And Maintenance
7. DAILY CARE AND MAINTENANCE Clean the scale with a soft and damp cloth. If necessary, apply a mild detergent. Do not use any harsh, abrasive material, acetone, volatile solvent, thinner or alcohol for cleaning. Verify the accuracy of scale periodically. Re-calibrate the scale if necessary. - Page 18 KONFORMITÄTSERKLÄRUNG Declaration of conformity Déclaration de conformité Die ichtselbsttätigen Waage The non-automatic weighing instrument L'instrument de pesage à fonctionnement non automatique Hersteller: Universal Weight Enterprise Manufacturer: Fabricant Co., Ltd. Typ/Modell: Type/Model: Type/modèle: Nr. der EG-Bauartzulassung (gegebenen falls): T6160 No of the EC type-approval certificate (where applicable): Nº...
