Page 1
1705N / 1705GN WEIGHING INDICATOR OPERATION MANUAL PLEASE READ THIS MANUAL VERY CAREFULLY BEFORE ATTEMPT TO OPERATE THE INDICATOR MAY 2003 Specifications subject to change without prior notice...
Page 3
2. OPERATION PANEL LAYOUT AND DESCRIPTIONS 2.1 FRONT PANEL ILLUSTRATION SIGNAL DISCRIPTION(¡ ¿ ) ¡ G i ndicator is charging and operating POWER ¡ G t his indicator means the tare function is in effect TARE ENTERED ¡ G s cale is now at a zero weight status ZERO ¡...
Page 4
¡ G P ress this key to enter parameter setting / calibration (when Calibration Switch is at ON position) ¡ G P arameter Setup Key (to be used with SET)¡ C ¡ G C alibration Key (to be used with SET)¡ C STANDBY ¡...
Page 5
3.1 LOAD CELL SIGNAL CABLE CONNECTION EXC+ EXC+ SEN+ SEN- SIG- SIG+ EXC- SIG+ SIG- S.G. EXC- 3.2 RS-232 INTERFACE (D-SUB 9PIN) Pin Assignment¡ G Pin No. Signal 1705N shorted internally 1705N Simple setup, only need to connect PIN 2¡ A 3 ¡ A 5...
Page 6
3.3 PRINTER INTERFACE (D-SUB 25PIN) Pin Assignment¡ G Centronics parallel standard Pin No. Signal STROBE DATA1 DATA2 DATA3 DATA4 DATA5 DATA6 DATA7 DATA8 BUSY 18~25 3.4 OP5 External Display Interface (4PIN) Pin Assignment¡ G Pin No. Signal DATA...
Page 7
4. SETTING 4.1 FUNCTION SETTING When plug in the power, display will show “1705n.xx”. If Calibration Switch in the back of the indicator is at ON position, then POWER signal and TARE signal will light up. Press SET and display will show “SEt”, press TARE to enter setup menu. Utilize ZERO or TARE to select the function that intend to set, such as Ad, kEY tSt, etc.
Page 9
[SET] [ZERO] or [TARE] 4.1.7 Unit Weight Units: ¡ G k ilogram ¡ G g ram ¡ G m etric ton ¡ G p ound [SET] [ZERO] or [TARE] dAtA FormAt1 FormAt2 4.1.8 RS-232 Transmission Format: FORMAT 1 ¡ A ¡...
Page 10
[SET] 4.1.10 o000000 Enter Password Setup Procedures: o000000 enter old password (if password were never set before, press SET) ¡ ö ¡ ÷ n000000 enter new password (use -, +, to shift position and increase or decrease value) -000000 reconfirm the new password [SET] [SET] [ZERO] or [TARE]...
Page 11
Maximum Capacity: as long as division/full capacity 1/30000, then the full C03000 capacity can be set freely. Division: it is repeat in the cycle of 1, 2 5, 10, 20, 50. When the maximum capacity is set, the program can automatically determine the adequate division with as if the maximum display resolution is 1/30000.
Page 12
Procedures Display Shows a. Enter selection which shows “¡ ¿ ” ¡ ¿ b. Press ZERO and indicator will show “cAL._0”. It cAL-0 means scale is now calibrating zero point. Make sure the platform is empty with everyone removed. c. Press SET and if display shows “¡ ¿ ..”, then ¡...
Page 13
5. TROUBLE SHOOTING ZERO CALIBRATION When the error messages appear on the display, the calibration is invalid. Follow theses guide step by step to solve the problems. A A A A A A A a. Poor connection —To check the connector wirings b.
Page 14
3. - - - - - - - The output signal of Load Cell is inadequate for Span Calibration. —To decrease the Display Resolution. –To change Load Cells with higher output signal. 4. U U U U U U U a.
