- Page 1 Service Manual 32” Medviron Overbed Table...
- Page 2 Table of Contents Section 1 Caster Replacement Section 2 Plug Replacement Section 3 Top Replacement Section 4 Gas Spring Replacement Section 5 Vanity Service...
- Page 3 Section 1: Service Instructions for MedViron Overbed Table Caster Replacement This manual is intended for trained professionals for adjustment of the MedViron Overbed Table. Any action not outlined in this manual may result in voiding of the warranty. Tools required...
- Page 4 Section 2: Service Instructions MedViron Overbed Table Base Plug Replacement This manual is intended for trained professionals for adjustment of the MedViron Overbed Table. Any action not outlined in this manual may result in voiding of the warranty. Tools required ...
- Page 5 Section 3: Service Instructions OBT 32” Top Replacement This manual is intended for trained professionals for adjustment of the Medviron Overbed Table. Any action not outlined in this manual may result in voiding of the warranty. Tools required 5/32” Allen wrench #2 Square driver bit (Provided) 3.0 Remove the top...
- Page 6 Section 4: Service Instructions – Gas Spring Replacement MedViron 32” Overbed Table This manual is intended for trained professionals for adjustment of the MedViron Overbed Table. Any action not outlined in this manual may result in voiding of the warranty.
- Page 7 Remove the top washer by removing the 2 screws that are attached to the upper column, NOTE: keep hold of the upper column while removing the screws to prevent the column from dropping. Next loosen the 2 nuts holding the gas spring to the top washer. Remove the top nut & the top washer & set aside (Figure 5).
- Page 8 Attach the top as shown in Section 3. Section 5: Service Instructions Vanity Tray Replacement This manual is intended for trained professionals for adjustment of the Medviron Overbed Table. Any action not outlined in this manual may result in voiding of the warranty.
- Page 9 Raise the unit to its fullest extension. In most cases, the vanity tray can be removed by pulling the tab past the stop. If the stop is too tight, a slotted screw driver may be used to lightly pry the stop. The vanity can be replaced the same way it was removed. Replacing the vanity tray If replacing the vanity, the rails may need adjustment.
