- Page 1 CD51 Indoor Dome Camera Setup...
-
Page 2: Table Of Contents
In the box What you’ll need Connect Contents Mount Adjust Secure Support... -
Page 3: In The Box
In the box 1 CD51 indoor dome camera 1 Mount plate 1 Mounting template 1 T10 security torx screwdriver 4 Mounting screws and wall anchors 3 Machine screws, washers and wing nuts CD51 Indoor Camera C,D,E 3 machine screw, washers and wing nuts Wall mount 4”... -
Page 4: What You'll Need
What you’ll need • A working internet connection • 802.3af Power over Ethernet (PoE) switch, or a PoE injector. For operation below -20° C, use 802.3at PoE. • A smartphone or laptop • A #2 Phillips screwdriver or power drill with a #2 Phillips driver bit •... -
Page 5: Connect
Connect Use the provided T10 security torx security screwdriver to loosen the screws and lift the cover. - Page 6 Insert the ethernet cable into ethernet port. Scan the Go to www.verkada.com/start QR code for easy camera registration and setup, or proceed to www.verkada.com/start. Connect -...
-
Page 7: Mount
Mount Mount the camera on a wall or ceiling. Try to keep the camera 8 to 10 feet above the ground. - Page 8 For best night vision, avoid overhangs or obstructions. These may reflect the camera’s IR illumination and reduce the image clarity in night mode. Mount -...
- Page 9 To remove the mount plate, loosen the Use the provided mounting template to mark mount plate screws and twist the camera wall mount holes. For a junction box mount, counter-clockwise. Lift the camera vertically use the mounting template to determine the off the base plate and set aside.
- Page 10 1/8 inch 1/4 inch For a solid material like wood or metal, drill For drywall, drill 1/ 4 inch holes. Insert plastic 1/8 inch pilot holes. Drive mounting screws anchors into holes and drive mounting directly into the pilot holes. screws into anchors.
- Page 11 To secure the camera, place it over the mount plate Plug in the camera. The status LED will turn orange screws and twist counter-clockwise. Tighten the to indicate the camera has power. The LED will turn mount plate screws with a Phillips screwdriver. blue to indicate the camera is active.
- Page 12 Gently pull the cable through the through-hole so it has some slack, but will not interfere with the top cover. Pulling the ethernet cable too tight will strain the cable which may impact data performance. Too much slack in the ethernet cable may create top cover installation issues.
-
Page 13: Adjust
60˚ 350˚ Adjust 350˚ Adjust your camera to the desired viewing angle. Use the online stream to confirm image orientation. Image can be flipped 180˚ online in Command. - Page 14 Lens Face Image orientation Image Orientation Default image orientation is indicated by markings on the lens face. Video orientation is also adjustable from within the Verkada application. Adjust -...
-
Page 15: Secure
Secure To secure the camera, align the top shell security holes with the baseplate and place the top shell back into its original position. Tighten the security screws using the provided T10 security torx screwdriver. - Page 16 Secure -...
-
Page 17: Support
Thank you for purchasing a Verkada camera. If for any reason things don’t work right or you need Support assistance, please contact us immediately. Sincerely - The Verkada Team www.verkada.com/support... - Page 18 NOTE: 1. Maintenance and repair work must always be carried out by qualified technical personnel. Disconnect power from the unit when performing a maintenance task. 2. Wiring methods used for the connection of the equipment to earth shall be in accordance with the National Electrical Code, ANSI/NFPA 70, and the Canadian Electrical Code, Part 1, CSA C22.1.
- Page 19 For additional support please contact us directly at +1 (833) 837-5232 or support@verkada.com...
