Building Interfaces
24 - Building Interfaces
Ports 1-16 (Continued)
DB37-1 LFH60
Pair
Source Dest
J1-18 J2-49
J1-19 J2-50
J1-20 N/C
J1-21 N/C
J1-22 J2-40
J1-23 J2-39
J1-24 J2-39
J1-25 J2-45 1B
J1-26 J2-15 2B
J1-27 J2-14 3B
J1-28 J2-13 4B
J1-29 N/C
J1-30 J2-12 5B
J1-31 J2-11 6B
J1-32 J2-10 7B
J1-33 J2-9 8B
J1-34 J2-51
J1-35 J2-52
J1-36 J2-53
J1-37 N/C
DB37-2
Signal
Source
V+ J3-18
V+ J3-19
J3-20
J3-21
SIG GND J3-22
SIG GND J3-23
SIG GND J3-24
RXCLK- J3-25
RXDATA- J3-26
RXDATB- J3-27
RXCNVT- J3-28
J3-29
TXDATB+ J3-30
TXDATA+ J3-31
TXCLK+ J3-32
TXCNVT+ J3-33
V+ J3-34
V+ J3-35
V+ J3-36
J3-37
RocketPort INFINITY User Guide: 2000465 Rev. G
Ports 17-32 (Continued)
LFH60
Pair Signal
Dest
J2-56 V+
N/C
N/C
N/C
J2-34 SIG GND
J2-33 SIG GND
J2-32 SIG GND
J2-7 1B RXCLK-
J2-6 2B RXDATA-
J2-5 3B RXDATB-
J2-4 4B RXCNVT-
N/C
J2-3 5B TXDATB+
J2-2 6B TXDATA+
J2-1 7B TXCLK+
J2-60 8B TXCNVT+
J2-57 V+
J2-58 V+
J2-59 V+
N/C
