The legend below describes the antenna types and how they will be represented in a sam-
ple antenna configuration:
Antenna Topology Legend
Antenna Symbol
Antenna Type
Vantage Pro2
Console
Weather
Envoy
Vantage Pro2
Wireless
Repeater
Any
Vantage Pro2
Station
Omni-directional
Long Range
Repeater Antenna
Yagi (Directional)
Long Range
Repeater Antenna
