- Page 1 Quality Assurance Guide ASSEMBLY INSTRUCTIONS HEAVY DUTY 5 SHELF STORAGE UNIT JB5TRHDSR This design and instruction booklet is subject to copyright. www.officeworks.com.au 1 Carton For spare parts or hardware call 1300 OFFICE （1300 633 423） 1 / 10...
- Page 2 Estimated Assembly Time: 30 minutes Furniture Assembly Instructions Style Guide Customer Service Contact Details Spare Parts & Hardware 1300 OFFICE （1300 633 423） People Required General Advice 2 / 10...
- Page 3 Tools Required CAUTION: Do not use tools other than those required, as this can damage your new item. NOTE •Please check you have all hardware before assembling. •If you are missing any hardware, please contact 1300 OFFICE（1300 633 423）. •Please ensure you have the name of the item, required hardware part and quantity. •Please retain your receipt as proof of purchase to validate your warranty.
- Page 4 Furniture Assembly Instructions Style Guide Parts List /Hardware List Part Number: Part Number: HW5TRHDSSB HW5TRHDSLB Post x8 Long beam x10 Short beam x10 Part Number: Part Number: HWCOUPTRSR HWENDCAPSR Shelf x5 Coupler x4 Post cap x16 Included Hardware: Part HWFASTRSR Fastener x2 4 / 10...
- Page 5 Assembly Furnitur Step 2 Step 1 Tap Lightly Shelf Ledge Post Slot Points Down 6 x4 Step 3 Step 4 5 / 10...
- Page 6 Furniture Assembly Instructions Style Guide Step 5 Step 6 Step 7 Step 8 6 / 10...
- Page 7 Furniture Assembly Instructions Style Guide Step 9 Step 10 5 x4 Step 11 Step 12 7 / 10...
- Page 8 Furniture Step 13 Step 14 Assembly WARNING: Serious or fatal crushing injuries can occur from furniture tip-over. To prevent this item from tipping over it must be permanently fixed to a wall. An anchor kit suitable for plaster walls is included with this item. Different wall materials may require a different anchor kit.
- Page 9 Furniture Assembly CAUTION The shelving unit is designed to carry up to 350kg per shelf. The product is intended to hold the maximum weight indicated. Exceeding the maximum weight will result in instability and may cause injury. Place equipment onto shelves evenly and ensure items do not overhang at sides, as that ...
- Page 10 Warranty 8 years Product Warranty - valid for Australian customers only Officeworks Ltd warrants that this product will be free from defects and work as intended for 8 years from the date of purchase by the original customer. If the product has any defects or does not works as intended during the Warranty Period, Officeworks will ,at its election and at its expense,repair or replace the product.
