- Page 1 ASSEMBLY INSTRUCTIONS SHELF UNIT JB5TRBLSR...
-
Page 2: Tools Required
Tools Required Hardware List PARTS INVENTORY CHECKLIST 5 Shelf A MDF shelves B Short Shelf Supports C Long Shelf Supports D Leg Angle Sections E Leg Angle Joiners F Plastic Floor Protectors G Nuts and Bolts Alternative assembly configurations:... - Page 3 Decide on the position you require the bottom shelf to be. Fit 1 short shelf support between the 2 leg angles. Repeat this again making sure that the same short shelf support is at the same height. Now fit the 2 long shelf supports matching the 2 short shelf supports.
- Page 4 Fit the floor protectors provided on the end of each leg. Assembling as a standard bench Refer to Step 1 and Step 2, except in Step 2, the centre 4 shelf supports go to the top of 4 leg angles and move the bottom 4 midway to suit your needs.
