INSTALLATION INSTRUCTIONS
2017 G3 Full / Front Enclosure / Double Canopy
V322 CC - 2019
PARTS LIST
1 Bow Canopy Frame (Figure 3)
1 Bow Canopy
1 Bow Canopy Boot
TOOLS REQUIRED
Measuring Tape
Center Punch
Drill
5/ 1 6" Drill Bit
Pencil
Phillips Screwdriver
2 Sets SAE Allen Wrenches
WARNING
INDICATES POTENTIAL HAZARD
THAT COULD RESULT IN DEATH
OR INJURY
Dowco Marine, Inc. | 1610 Frisco Road, Lebanon MO 65536 | dowcomarine.com | (800) 404-5252
BOW HARDWARE PACKAGE
2 - "H" Brackets (1 1/4")
4 - 1/4"-20 Barrel Nuts
2 - 1/4"-20 Short Shoulder Bolts
2 - Deck Buttons w/ 1/4"-20 x 1.5" Bolt
2 - 5/ 1 6x2" Bolts
2 - Lock Washers
2 - 5/ 1 6" Tri Wing Knob
2 - Plastic Shoulder Washers
8 - Self Drill Scews
CAUTION
INDICATES POTENTIAL
HAZARD THAT COULD
RESULT IN BOAT DAMAGE
NOTE
INDICATES SPECIAL INFORMATION
TO MAKE MAINTENANCE EASIER
OR INSTRUCTIONS CLEARER
140304-00 | 06/18
