INSTALLATION INSTRUCTIONS
2012-18 Bimini Top
Mako Pro 17 Skiff CC
PARTS LIST
DESCRIPTION
Top / Boot / Frame / Hardware
Frame
Boot
Top / Boot
Top
Hardware Kit
FIG. 1
NOTE:
1. Main frame buttons to be mounted with the release latch
toward front of boat. Other buttons mounted with release
latch to the rear.
2. All measurements to the center-line of buttons.
3. All deck buttons must be mounted with thru-bolts. See
Detail A.
Dowco Marine, Inc. | 1610 Frisco Road, Lebanon MO 65536 | dowcomarine.com | (800) 404-5252
PART NUMBER
73582-XX
20166-99
44117-XX
44118-XX
44116-XX
20161-00
130"
40"
FROM CENTER OF CLEAT
90"
44 1/2"
FROM CENTER OF CLEAT
46 1/2"
FROM CENTER OF
CLEAT
DETAIL A
54"
1/4-20 X 2"
FLAT HD FASTENER
DECK BUTTON
FLAT WASHER
1/4-20
LOCKING NUT
FIBERGLASS
140322-00 | 02/19
