Installation - Instructions
Using the mounting template or your camera,
1
mark and drill the necessary holes to mount the
bracket to a wall or ceiling.
Pull a necessary wires through and make the
2
proper connections. See pages 14-15.
Remove the camera's dome and decorative ring
3
and use the two mounting screws to install the
camera on the wall or ceiling. See page 16 for
tilting and pan adjustment options.
Adjust the camera's pan and tilt as needed. See
4
page 15 for more information.
When the installation is completed, place the
5
camera's dome over the camera's body.
Detach the protection film from the dome and
6
place the decorative ring in place using the
stopper screw to complete the installation.
