The G4-40G-010-384T is best suited for Multi-40 Gb data centers.
G4-40G-010-384T technical specifications
The technical specifications for the product are shown below.
System
Deployment
Base storage
Max storage
Lights Out Management (LOM)
Redundant OS drive
OS drive hot swappable
OS drive size
RAID drive hot swappable
RAID version
Rail kit
Operating system
Physical
Height
Width
Depth
Weight (with mounted rail kit or portable
unit without a travel case)
Weight (handling or portable unit in a
travel case)
Media
Monitoring interfaces
Speed
Accepted transceivers
Performance
g440g010384t - 1
G4-40G-010-384T
-
40 Gb data center
384 TB
384 TB
Yes
Yes
Yes
1 TB
Yes
60
Yes
Windows 2012 R2
-
8U
19 in
26.5 in
216 lbs
227 lbs
-
8
1/10 Gb
SFP/SFP+
1
-
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G4-40G-010-384T and is the answer not in the manual?

Questions and answers

Summary of Contents for Viavi G4-40G-010-384T

  • Page 1 G4-40G-010-384T The G4-40G-010-384T is best suited for Multi-40 Gb data centers. G4-40G-010-384T technical specifications The technical specifications for the product are shown below. System Deployment 40 Gb data center Base storage 384 TB Max storage 384 TB Lights Out Management (LOM)
  • Page 2: Parts List

    QSFP28 tranceivers may be SR4, LR4, or BIDI. Parts list Each appliance comes packed in a box or several boxes. The boxes contain the various components necessary for a successful installation. The G4-40G-010-384T appliance box contains the following components: 1 Head unit with RAID drives preinstalled ●...
  • Page 3 1. Mount the appliance in your cabinet. Refer to the instructions on VIAVI Rail Kit (page 10). Use a server lift if necessary. Do not remove the drives from the chassis. 2. Connect the cables.
  • Page 4 6. Turn on the head unit (A1). 7. Set the ip address. 4 | © 2020 Viavi Solutions (3 Feb 2020) — viavidoc.com/observerstart...
  • Page 5 Next, give the ETH0 IP address and IPMI port address, if using, to the Observer administrator. They need the addresses to add this GigaStor probe to Observer to capture network traffic with a probe instance. SFP, SFP+, QSFP+, and QSFP28 transceivers are sold separately. 1.  G4-40G-010-384T installation | 5...
  • Page 6: Configuring Your System

    Set the IP address of the hardware appliance while you still have physical access to it, such as immediately after it is racked and cabled. Setting the IP address ensures the hardware appliance has a visible and permanent network presence. 6 | © 2020 Viavi Solutions (3 Feb 2020) — viavidoc.com/observerstart...
  • Page 7 Prerequisite(s):   switch or keyboard, monitor, and mouse are connected. The user input devices ♦ or KVM switch are only temporarily needed to set the IP address, so you can disconnect them after the IP address is set. The IP, subnet, and gateway or router addresses are available and known to you. ♦...
  • Page 8    How to configure the JBOD IPMI port The JBOD chassis offers intelligent management with IPMI providing hardware health monitoring and remote power control. 8 | © 2020 Viavi Solutions (3 Feb 2020) — viavidoc.com/observerstart...
  • Page 9 Prerequisite(s):   Your host computer must be on the same network as the JBOD IPMI interface. If necessary, change your host IP to 192.168.1.10/24. JBODs must be monitored separate from any head unit. Like the head unit, there is no audible alarm.
  • Page 10 3. Slide the rail toward the front of the chassis to hook the inner rail onto the side of the chassis. 4. (Optional) If desired, secure the rail with two flat head M4 x 4mm screws (and washers) as illustrated. 5. Repeat for the other inner rail. 10 | © 2020 Viavi Solutions (3 Feb 2020) — viavidoc.com/observerstart...
  • Page 11 Figure 9: Installing the inner rails 6. Identify the outer rack rails. 7. Press upward on the locking tab at the rear end of the middle rail. 8. Push the middle rail back into the outer rail. 9. Hang the hooks on the front of the outer rail onto the square holes on the front of the rack. If desired, use screws (and washers) to secure the outer rails to the rack.
  • Page 12: How To Remove The Server From The Rack

    (North/South America) uknisupport@viavisolutions.com (EMEA/APAC) Support hours are 7:00 A.M. to 7:00 P.M. CST/CDT (for North and South America) and 8:00 A.M. to 5:00 P.M GMT (EMEA and APAC). 12 | © 2020 Viavi Solutions (3 Feb 2020) — viavidoc.com/observerstart...
