- Page 1 WEATHERSHIELD CANOPIES Equipment Canopies Photo may show a different but similar model. STK# DIMENSIONS 104321 6’ W x 10’ L ©2008 FarmTek® 104322 6’ W x 20’ L All Rights Reserved. Reproduction 104323 6’ W x 30’ L is prohibited without permission.
-
Page 2: Safety Precautions
BEGIN TO ASSEMBLE THE SHELTER. • Never erect the structure under power lines. Thank you for purchasing this FarmTek® shelter. When • Identify whether underground cables and pipes are properly assembled and maintained, this product will present before preparing the site or anchoring the provide years of reliable service. -
Page 3: Assembly Procedure
These words and phrases are common to most joints and to fasten brackets to rafters. FarmTek® shelters and identify the different parts of the shelter. (Some are used in this document. Others may not apply to this particular shelter.) These terms describe the shipped parts and can also be found on the materials list/spec sheets included with the shipment. -
Page 4: Required Tools
WEATHERSHIELD CANOPIES REQUIRED TOOLS ALTERNATIVE ASSEMBLY INFORMATION The following list identifies the main tools needed to These instructions describe assembling the entire roof assemble the shelter. Additional tools and supports may be section of the shelter first. The frame is then lifted and the needed depending on the structure, location, and legs added. - Page 5 WEATHERSHIELD CANOPIES The following graphics and photos will help you identify the different parts and show you how they are used. (Not all parts are shown.) 104651 102191 Cross Coupler 3-Way Coupler 102192 102205 CC4595 4-Way Coupler Tie Down 8'' Snugger Ball Tee Coupler Revision date: 07.21.08...
- Page 6 WEATHERSHIELD CANOPIES ADDITIONAL PARTS IDENTIFICATION NOTES In some instances, there can be differences between the parts that are shown and referenced in the instructions and the parts that are shipped with the shelter. These differences do not affect the integrity of the shelter, but can change the assembly procedures.
- Page 7 WEATHERSHIELD CANOPIES WeatherShield Canopies ASSEMBLE THE MAIN ROOF FRAME (ALL LENGTHS) This section is an overview of the process for assembling NOTE: Diagrams show where to install your roof frame. See illustration below to identify main parts Tek screws if the couplers are not of the frame.
- Page 8 WEATHERSHIELD CANOPIES INSTALL LOWER PURLINS AND LEGS This section is an overview of the process for attaching the lower purlins and legs to the roof frame. See illustration below to identify main parts of the frame. 1. Using the upper leg pipes, insert the legs into the 3-way 5.
- Page 9 WEATHERSHIELD CANOPIES INSTALL THE MAIN FRAME COVER After the frame is properly squared and anchored, install the main cover. Gather the parts: • Snugger ball tie downs (#CC4595) • Main cover NOTE: Assistance is required to install the main cover. WARNING: To prevent property damage and personal injury, do not install the cover on a windy or stormy day.
-
Page 10: Care And Maintenance
Never pack the covers when they are wet. Always dry them before you pack the shelter. • For replacement or missing parts, call 1-800-245-9881 for assistance. NOTE: With the exception of Truss Arch buildings, FarmTek® shelters and greenhouses do not have any tested loading criteria. Revision date: 07.21.08... - Page 11 WEATHERSHIELD CANOPIES 7'-5 5/16" Height QUICK START GUIDE 6' Wide Equipment Canopies 5'-6 3/4" Endwall Height 6'-0" Width FRONT Grid Represents 12" Squares 104321 (6' X 10') 104322 (6' X 20') 104323 (6' X 30') Revision date: 07.21.08...
