HUNTLEY
OWNERS MANUAL
REV 07.23.19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HUNTLEY GM-020 and is the answer not in the manual?

Questions and answers

Related Manuals for GLIDEAWAY HUNTLEY GM-020

Summary of Contents for GLIDEAWAY HUNTLEY GM-020

  • Page 1 HUNTLEY OWNERS MANUAL REV 07.23.19...

  • Page 2: Table Of Contents

    OWNERS MANUAL: HUNTLEY Contents Safety Information What Is Included Assembly – Base Location of Controls – Remote Operation – Main Operation – Linking the Remote Troubleshooting Available Accessories Online Resources User Info Please take a moment and write down the serial number in the space provided below, in case you need to refer to it in the future.

  • Page 3: Safety Information

    OWNERS MANUAL: HUNTLEY Safety Information DANGER! OPEN BOX IN DO NOT OPEN FROM FLAT POSITION VERTICAL POSITION. THIS CAN DAMAGE BASE. ATTENTION! IMPORTANT SAFETY INSTRUCTIONS. SAVE THIS MANUAL! PLEASE READ THESE INSTRUCTIONS THOROUGHLY BEFORE USING THIS PRODUCT. PROPER OPERATION OF YOUR ADJUSTABLE BED IS NECESSARY TO ENSURE THE LONG LIFE AND DURABILITY YOU EXPECT FROM A HIGH-QUALITY PRODUCT.
  • Page 4 OWNERS MANUAL: HUNTLEY Safety Information WARRANTY WARNING! This bed is specifically designed to require no maintenance by you, the user. Any opening or tampering with the control box, motors or hand controls (with the exception of the battery compartment, if equipped) will void the warranty.
  • Page 5 OWNERS MANUAL: HUNTLEY Safety Information SMALL CHILDREN AND PETS WARNING Immediately dispose of all packing materials, as they can pose a smothering risk to small children and pets. Injury could also occur if children or pets are permitted to play on or under the bed. Do not allow children to operate this bed without adult supervision.

  • Page 6: What Is Included

    OWNERS MANUAL: HUNTLEY What’s Included Before discarding any packing materials, check the adjustable base shipping carton and verify the following items are included: (2) Base Pieces (1) Power Supply (1) Remote Control (not attached to the base) (1) Foot Mattress Retainer (1) AC Cord (4) 15”...

  • Page 7: Assembly - Base

    OWNERS MANUAL: HUNTLEY Assembly – Base It is HIGHLY recommended to use two people for the installation of this product. To assemble, please perform the following steps: Carefully lift both Base Pieces from the shipping carton, keeping the unit’s topside down. Remove the plastic wrapping from the bottom to access the bases.
  • Page 8 OWNERS MANUAL: HUNTLEY Assembly – Base (cont’d) Please refer to diagram when assembling the adjustable bed. FIGURE Head Motor NOTE: Make sure wire connected to Power Supply is routed UNDER the main metal Control Box frame and lifting mechanism. Routing wires on Power Supply top of the metal frame are likely to...
  • Page 9 OWNERS MANUAL: HUNTLEY Assembly – Base (cont’d) Connect the Foot motor connector cable to the Head motor connector cable. LOCK REFER TO FIGURE A ON PAGE 8. NOTE: The Head and Foot motors are labeled per illustration. Insert the AC cord into the power supply. IMPORTANT: DO NOT PLUG THE BASE INTO THE AC OUTLET YET.
  • Page 10 OWNERS MANUAL: HUNTLEY Assembly – Base (cont’d) Insert the Mattress Retainer Bar upright as shown. Lift the battery cover and insert the two AAA size batteries (included) into the remote as shown in the figure. Replace the battery cover. Remote is already linked with the base. TO LINK REMOTE: If the remote is not linked, see page 14.
  • Page 11 OWNERS MANUAL: HUNTLEY Assembly – Base (cont’d) Insert AC plug into an AC outlet having 100-240V AC, 50/60Hz. Avoid outlets that work only with light switch. Initial use of base requires additional run time. Simply press the Head Up button on the remote until the head section begins to lift.

  • Page 12: Location Of Controls - Remote

    OWNERS MANUAL: HUNTLEY Location of Controls — Remote Head Up Foot Up Foot Down Head Down Operation — Main Press and hold the Head Up button to raise the Head position. Release button when desired position is reached. Press and hold the Head Down button to lower the Head position.
  • Page 13 OWNERS MANUAL: HUNTLEY Operation — Main (cont’d) NOTE: EMERGENCY LOWERING: If you cannot find the remote control, locate and press the Emergency Flat button located on the main control box on the bottom of the bed (shown to the left).

  • Page 14: Operation - Linking The Remote

    OWNERS MANUAL: HUNTLEY Operation – Linking the Remote Connecting 1 Remote to 1 Base Double click the PAIR button on the control box (light will go on). Simultaneously press & hold the FLAT and HEAD UP buttons. When the LED light on the control box turns off, release the two buttons.

  • Page 15: Troubleshooting

    OWNERS MANUAL: HUNTLEY Troubleshooting In the event the base fails to operate, investigate the symptoms and possible solutions provided below: Remote control illuminates Unplug power cord, wait 30 seconds and plug in to reset electronic ■ ■ and appears to be operable, components.

  • Page 16: Available Accessories

    OWNERS MANUAL: HUNTLEY Available Accessories Item Part Number High Profile Legs CB12LEG18.5 (Overall Bed Height 18.5”) Headboard Bracket Kit CB18HBBRKT To order an accessory, please call 1-855-581-3095 Resources CUSTOMER SERVICE 1-855-581-3095 VISIT US ONLINE glideaway.com...
  • Page 17 HUNTLEY Sleep Well. Live Better. Be Your Best. 8226 LACKLAND RD. ST. LOUIS, MO 63114 | GLIDEAWAY.COM | 314.426.3999...
