Congratulations on your purchase of our SUNJOY Heirloom Slate Round Table. Our clear,
easy to follow, step-by-step instructions will guide you through the assembly process from
start to finish.
WARNING:
THIS UNIT IS HEAVY! For safety, DO NOT assemble this item alone. 4 people are
recommended for safe assembly.
Keep all children and pets away from assembly area. Children and pets should be supervised
when they are in the area of the Table construction.
Keep assembly area at least 6 feet from any obstruction such as a fence, garage, house,
overhanging branches, laundry line or electrical wires.
Some parts may contain sharp edges. When assembling and using this product, basic safety
precautions should always be followed to reduce the risk of personal injury and damage to
the product. Please read all instructions before assembly and use.
Check all bolts for tightness before use. IMPORTANT - check and tighten bolts often to keep
them secure!
Please take time to read these instructions thoroughly and follow each step carefully for safe and easy
operation. Keep this manual for future reference.
For technical assistance on assembly or replacement parts, call Sunjoy Industries at 1-866-578-6569
from 8:30AM to 5:30PM EST, or email us at sams@sunjoygroup.com, or visit
assistance.
Heirloom Slate Round Table
Item# L-DN1059SST-D
IMPORTANT
1
www.sunjoydirect.com
for
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Sunjoy L-DN1059SST-D
Summary of Contents for Sunjoy L-DN1059SST-D
- Page 1 Heirloom Slate Round Table Item# L-DN1059SST-D Congratulations on your purchase of our SUNJOY Heirloom Slate Round Table. Our clear, easy to follow, step-by-step instructions will guide you through the assembly process from start to finish. WARNING: THIS UNIT IS HEAVY! For safety, DO NOT assemble this item alone. 4 people are recommended for safe assembly.
- Page 2 Parts List Description Table Top Bottom Fixed Ring Top Fixed Ring Side Panel Door Panel Handle (Pre-assembled on F) Umbrella Hole Cap Bolt M6×20 Bolt M6×35 Bolt M8*45 Bolt M6*15 (Pre-assembled on F) Spring Washer M6 Flat Washer M6 Spring Washer M8 Flat Washer M8 Wrench M6 Wrench M8...
- Page 3 Step 2: Use Bolt (AA), Spring Washer (EE) and Step 3: Use Bolt (BB), Spring Washer (EE) and Flat Washer (FF) to lock Side Panel (E), Door Flat Washer (FF) to connect Top Fixed Ring (D) Panel (F) and Leg (B). (Note: don’t mess with the with Leg (B).
- Page 4 877-738-7325 to obtain it from V-SEAL Sealers. Limited Warranty: Sunjoy Industries warrants to the original purchaser that this item is free from defects in workmanship and materials for a period of 1 year from the date of purchase, provided the item was factory-sealed at the time of purchase and is maintained with care and used only for personal, residential purposes.
