Dacor Integrated IF36LNBOL Dimensions
Dacor Integrated IF36LNBOL Dimensions

Dacor Integrated IF36LNBOL Dimensions

Dacor integrated if36lnbol: specifications
Hide thumbs Also See for Integrated IF36LNBOL:

Advertisement

The new line of Epicure
ment other luxury appliances by Dacor, and deliver the complete Dacor Kitchen
Experience - from food preservation, preparation, cooking to clean up.
Size to Fit Every Kitchen
Choice of Epicure or Millennia Handles
Electronic Touch Control Panel
Interior Storage Features
36" Features
42" & 48" Features
and Integrated™ BUILT-IN REFRIGERATORS comple-
®
Dacor's new line of built-in refrigerators come in 48", 42" and 36".
Refrigerators are available in stainless steel and overlay models.
Epicure and Millennia handle options available for all models.
Door Open indicator light will flash, an alarm will sound and the interior
lights will turn off when door has been open for longer than 10 minutes.
The Over Temperature feature helps prevent food being spoiled. The
feature lets you know when either the refrigerator temperature rises above
48°F (9°C) or the freezer temperature rises above 15°F (-9°C) for longer
than 1-1/2hours.
Max Cool assists with periods of heavy ice usage, full grocery loads or
temporarily warm room temperature by lowering temperature in freezer and
refrigerator compartment. It will reset to normal temperatures after 24
hours unless manually turned off.
The Holiday Mode feature is designed for the traveler or for those whose
religious observances require turning off the lights and ice maker. All
models are Star-K certified and Sabbath compliant.
The Water Filter Indicator, located on the control panel, will help you know
when to change the water filter.
Crisper and deli drawers allow contents of drawers to be seen easily
from the outside; both are equipped with a gliding system which allows
drawers to move in and out easily.
Adjustable Glass Shelves help contain spills and provide added visibility.
Adjustable Gallon Door Bin can hold gallon size containers.
This model is a single door style with bottom drawer freezer.
ENERGY STAR® qualified.
LED lighting in meat drawer does not generate heat.
The Ice Maker is located in the freezer.
Stainless Steel door skin is replaceable if damaged.
Bright interior lighting in both compartments.
In-door Electronic Ice & Water Dispenser available in both sizes.
The In-door Electronic Ice & Water Dispenser easily accommodates over
sized cups, sports bottles, and tumblers.
Light-touch dispensing paddles push back so easily even a plastic foam
cup is filled without breaking, and the control lockout prevents little hands
from making a big mess.
The dispenser night light can be turned on manually or when in use.
Ice dispensing system has an ice bucket located in the door to increase
freezer capacity.
Ingredient Care Center -An electronically-controlled, temperature-adjustable
drawer ensures ingredients from cheeses and fresh produce to herbs and
meats - remain fresh for maximum taste and texture.
Cold air flows into the pan through the air duct between the freezer and
the refrigerator. Setting the controls allows more or less.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Integrated IF36LNBOL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Dacor Integrated IF36LNBOL

  • Page 1 The new line of Epicure ment other luxury appliances by Dacor, and deliver the complete Dacor Kitchen Experience - from food preservation, preparation, cooking to clean up. Size to Fit Every Kitchen Choice of Epicure or Millennia Handles Electronic Touch Control Panel Interior Storage Features 36”...
  • Page 2 48” 42” 36” 47-1/4” 41-1/4” 35-1/4” Refrigerator 83-3/8” 83-3/8” 83-3/8” Freezer TOTAL 25-3/8” 25-3/8” 25-3/8” Go to www.dacor.com - Installation & Specs for: Planning Guides • Installation Instructions • Use and Care Manual • IF42NBOL IF36LNBOL Style/Trim Epicure - Black Chrome...
