1. Turn the ignition on.
2. Press the Valet switch the pre-
programmed number of times to
disarm the VRS system.

g g l l o o s s s s a a r r y y o o f f t t e e r r m m s s

The "brain" of your system. Usually hidden under
Control Unit:
the dash area of the vehicle. It houses the microprocessor which
monitors your vehicle and controls all of the system's
functions.
Fault-proof Starter Interrupt
the security system which prevents the vehicle's starter from
cranking whenever the system is armed. The vehicle is never
prevented from cranking when the system is disarmed, in Valet
mode, or should the starter interrupt switch itself fail. Your
system is ready for this feature, however installation may require
additional labor.
: A physical connection to the system. An input can be
Input
provided by a sensor, pinswitch or through an existing system in
the vehicle, such as ignition or courtesy lights.
: Red light mounted somewhere in the vehicle. It is used to
LED
indicate the status of your system. It is also used to report trig-
gers and faults in the system or sensors.
26
: An automatic switch controlled by
