(see Table of Zones section). The system will retain this infor-
mation in its memory, and continue to chirp four or five times
each time it is disarmed, until the next time the ignition key is
turned on.
➜

table of zones

The zone number is the number of LED flashes used by the
system to identify a specific input. The standard input assign-
ments are listed below, along with spaces to write in any optional
sensors or switches you have had installed.
Zone - Number
of LED Flashes
1
2
3
4
5
If the Warning Zone response is triggered, the LED will not report
it.
note: Your system stores the last two triggered zones in
memory. If your system has been triggered but the LED
has been reset by turning on the ignition, your dealer can
still recall the last two zones that were triggered. Contact
your dealer for details.
© 2001 directed electronics, inc.
Description
Instant trigger - often used
for hood/trunk pinswitches
Instant trigger - a heavier impact
detected by the shock sensor
Door switch trigger
Instant trigger - for optional sensors
Ignition trigger
Dealer-Installed
Options
15
