Product End-of-Life Disassembly Instructions
Product Category: Personal Computers
Marketing Name / Model
[List multiple models if applicable.]
HP ProOne 460 G3 Non-Touch All-in-One Business PC
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions
for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU
directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
1.0 Items Requiring Selective Treatment
1.1 Items listed below are classified as requiring selective treatment.
1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as
applicable.
Item Description
Printed Circuit Boards (PCB) or Printed Circuit
Assemblies (PCA)
Batteries
Mercury-containing components
Liquid Crystal Displays (LCD) with a surface greater
than 100 sq cm
Cathode Ray Tubes (CRT)
Capacitors / condensers (Containing PCB/PCT)
Electrolytic Capacitors / Condensers measuring
greater than 2.5 cm in diameter or height
External electrical cables and cords
Gas Discharge Lamps
Plastics containing Brominated Flame Retardants
weighing > 25 grams (not including PCBs or PCAs
already listed as a separate item above)
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and toner
Components and waste containing asbestos
Components, parts and materials containing
EL-MF877-00
Template Revision B
Notes
With a surface greater than 10 sq cm
All types including standard alkaline and lithium coin
or button style batteries
For example, mercury in lamps, display backlights,
scanner lamps, switches, batteries
Includes background illuminated displays with gas
discharge lamps
Power cord
Include the cartridges, print heads, tubes, vent
chambers, and service stations.
PSG instructions for this template are available at
EL-MF877-01
Quantity
of items
included
in product
1
1
0
1
0
0
9
1
0
0
0
0
0
Page 1
Advertisement
Related Manuals for HP ProOne 460 G3
Summary of Contents for HP ProOne 460 G3
- Page 1 Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
- Page 2 refractory ceramic fibers Components, parts and materials containing radioactive substances 2.0 Tools Required List the type and size of the tools that would typically be used to disassemble the product to a point where components and materials requiring selective treatment can be removed. Tool Description Tool Size (if applicable)
- Page 3 MANUFACTURING PROCESS INSTRUCTIONS MECHANICAL ASSEMBLY MODEL : Pyxis400 Pyxis400 DISASS'Y SOP Sub-assembly name: Pyxis400 DISASS'Y SOP Document No.: Ethan Lai Written by: Revision: 1.00 Date: 2017/5/23 Page: 1 of 1 A.Current station version list: Station Version Station Version Station Version Station Version Station Version Station Version 1.00 1.00 1.00...
- Page 4 Standard Operation Procedure 1(1/1) : Pyxis400 DISASS’Y SOP Document No. Station : Remove Stand & pull open Rear Cover 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-fingered gloves Steps： 1. Take out Stand and put into the material box Step2: Pull up the hinge (Fig.
- Page 5 Standard Operation Procedure 2(1/1) : Pyxis400 DISASS’Y SOP Document No. Station : Take out Rear Cover 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-fingered gloves Steps： 1. Take out Rear Cover (Fig. 1, 2, 3). Follow the steps as Fig. illustrated. ...
- Page 6 Standard Operation Procedure 3(1/1) : Pyxis400 DISASS’Y SOP Document No. Station : Take out M/B shielding 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Full-fingered gloves Steps： 1. Unscrew (Torx Pin-Head × 4) all joints to take out M/B shielding (Fig. 1). ...
- Page 7 Standard Operation Procedure 4(1/1) : Pyxis400 DISASS’Y SOP Document No. Station : Take out Thermal Module 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Full-fingered gloves Steps： 1. Unscrew (Torx Pin-Head × 5) all joints to take out Thermal Module (Fig. 1). ...
- Page 8 Standard Operation Procedure 5(1/1) : Pyxis400 DISASS’Y SOP Document No. Station : Take out HDD and ODD 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： 1. Take out HDD (Fig. 1). Pull open the HDD bracket softly to the right, and push upward HDD to disconnect, then put it into the material box.
- Page 9 Standard Operation Procedure 6(1/1) : Pyxis400 DISASS’Y SOP Document No. Station : Take out I/O board 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-fingered gloves Steps： 1. Unscrew (Torx Pin-Head × 2) all joints to take out I/O board and disconnect I/O cable (Fig. 1, 2).
- Page 10 Standard Operation Procedure 7(1/1) : Pyxis400 DISASS’Y SOP Document No. Station : Take out DDR and CPU 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： 1. Take out DDR and put it into the material box (Fig.
- Page 11 Standard Operation Procedure 8(1/1) : Pyxis400 DISASS’Y SOP Document No. Station : Take out Vesa Mount 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： 1. Unscrew (× 5) all joints of Vesa Mount illustrated as Fig. 1. ...
- Page 12 Standard Operation Procedure 9(1/1) : Pyxis400 DISASS’Y SOP Document No. Station : Disconnect cables 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： 1. Disconnect cables from the connectors of M/B side, including Sate Power cable, ODD cable and HDD cable (Fig.
- Page 13 Standard Operation Procedure 10(1/1) : Pyxis400 DISASS’Y SOP Document No. Station : Take out screws and cables 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： 1. Follow the locations of cables from top to bottom illustrated as Fig. 1 to take out cables.
- Page 14 Standard Operation Procedure 11(1/1) : Pyxis400 DISASS’Y SOP Document No. Station : Take out Top Vent 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： 1. Unscrew (Torx Pin-Head × 5) all joints of Top Vent (Fig. 1). ...
- Page 15 Standard Operation Procedure 12(1/1) : Pyxis400 DISASS’Y SOP Document No. Station : Take out FAN & disconnect LVDS cable 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： 1. Unscrew (× 3) all joints of FAN (Fig. 1). ...
- Page 16 Standard Operation Procedure 13(1/1) : Pyxis400 DISASS’Y SOP Document No. Station : Take out Wireless LAN 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： 1. Tear off the acetate tape (Fig. 1). 2. First disconnect WLAN antennas, then unscrew (Cross ×...
- Page 17 Standard Operation Procedure 14(1/1) : Pyxis400 DISASS’Y SOP Document No. Station : Pull out Backlight cable 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： 1. Pull out Backlight cable from the hooks, then pull out it vertically from the top of connector on M/B (Fig.
- Page 18 Standard Operation Procedure 15(1/1) : Pyxis400 DISASS’Y SOP Document No. Station : Disconnect CCD cable & touch cable 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： 1. Disconnect CCD cable and touch cable from the connectors of M/B side, then pull out them from the hooks (Fig.
- Page 19 Standard Operation Procedure 16(1/1) : Pyxis400 DISASS’Y SOP Document No. Station : Take out SIDE BAND-R & unscrewing 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： 1. Unscrew (× 4) all joints illustrated as Fig. 1. ...
- Page 20 Standard Operation Procedure 17(1/1) : Pyxis400 DISASS’Y SOP Document No. Station : Take out SIDE BAND-L & unscrewing 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： 1. Unscrew (× 2) all joints illustrated as Fig. 1. ...
- Page 21 Standard Operation Procedure 18(1/1) : Pyxis400 DISASS’Y SOP Document No. Station : Unscrew the screws of cushions 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： 1. Unscrew (Torx Pin-Head × 4) all joints of BASE PAN (Fig. 1, 2). ...
- Page 22 Standard Operation Procedure 19(1/1) : Pyxis400 DISASS’Y SOP Document No. Station : Take out cushions & unscrew BOTTOM BAND 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： 1. Take out Cushion-R and Cushion-L (Fig. 1, 2). ...
- Page 23 Standard Operation Procedure 20(1/1) : Pyxis400 DISASS’Y SOP Document No. Station : Take out DC-IN cable & BOTTOM BAND 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： 1. Unscrew (Torx Pin-Head × 2) all joints of DC- IN cable (Fig.
- Page 24 Standard Operation Procedure 21(1/2) : Pyxis400 DISASS’Y SOP Document No. Station : Take out Speaker 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： 1. Unscrew (Torx Pin-Head × 4) all joints of Speaker (Fig. 2, 3). ...
- Page 25 Standard Operation Procedure 21(2/2) : Pyxis400 DISASS’Y SOP Document No. Station : Disconnect Speaker cable 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： Speaker 1. Pull out Speaker cable moderately from the CNTR hooks marked in red circles (Fig. 2). 2.
- Page 26 Standard Operation Procedure 22(1/1) : Pyxis400 DISASS’Y SOP Document No. Station : Take out M/B 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： 1. Unscrew (Torx Pin-Head × 8) all joints to take out M/B (Fig. 1). ...
- Page 27 Standard Operation Procedure 23(1/2) : Pyxis400 DISASS’Y SOP Document No. Station : Pull out Antenna cables 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： 1. Pull out Antenna cables moderately from the hooks from the left side to the right side (Fig. ...
- Page 28 Standard Operation Procedure 23(2/2) : Pyxis400 DISASS’Y SOP Document No. Station : Pull out Antenna cables 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： 1. Pull out the long side Antenna cable (Fig. 1). 2. Pull out the short side Antenna cable (Fig. 1). ...
- Page 29 Standard Operation Procedure 24(1/2) : Pyxis400 DISASS’Y SOP Document No. Station : Take out Camera 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： 1. Pull out the cable from the hooks marked in white circles (Fig. 1). 2.
- Page 30 Standard Operation Procedure 24(2/2) : Pyxis400 DISASS’Y SOP Document No. Station : Take out Camera 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： CCD switch 1. Take out CCD switch, then pull out the camera cable from Camera (Fig. 1, 2). ...
- Page 31 Standard Operation Procedure 25(1/1) : Pyxis400 DISASS’Y SOP Document No. Station : Take out Backlight cable 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： 1. Pull out Backlight cable from the connector of Panel (Fig. 1). ...
- Page 32 Standard Operation Procedure 26(1/1) : Pyxis400 DISASS’Y SOP Document No. Station : Unscrew Panel 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： 1. Unscrew (Torx Pin-Head × 6) all joints of Panel (Fig. 1, 2). ...
- Page 33 Standard Operation Procedure 27(1/1) : Pyxis400 DISASS’Y SOP Document No. Station : Take out BASE PAN 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： 1. Take out BASE PAN from Panel (Fig. 1, 2). Obliquely take out BASE PAN. 图...
- Page 34 Standard Operation Procedure 28(1/1) : Pyxis400 DISASS’Y SOP Document No. Station : Inspect BASE PAN 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： 1. Confirm there is no RF material shortage for BASE PAN, then put it into the material box. No leak No leak leak...
- Page 35 Standard Operation Procedure 29(1/1) : Pyxis400 DISASS’Y SOP Document No. Station : Take out LVDS cable 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： LVDS 1. Tear the handle, then pull out LVDS cable horizontally from the connector of Panel (Fig. ...
- Page 36 Standard Operation Procedure 30(1/1) : Pyxis400 DISASS’Y SOP Document No. Station : Take out Panel 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： 1. Take out Panel from Front Bezel (Fig. 3). 2. Inspect whether Front Bezel has obvious defect in the four side, back side and bottom Front side side (Fig.
- Page 37 Standard Operation Procedure 31(1/1) : Pyxis400 DISASS’Y SOP Document No. Station : Take out the brackets of Panel 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： 1. Unscrew (× 2) all joints to take out Bracket-R and Bracket-L (Fig.
- Page 38 Standard Operation Procedure 32(1/1) : Pyxis400 DISASS’Y SOP Document No. Station : Tear off Mylar 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： 1. Tear off the Mylar (× 3) of Bracket-R (Fig. 1). This step is only for Panel of Samsung. 2.
- Page 39 Standard Operation Procedure 33(1/1) : Pyxis400 DISASS’Y SOP Document No. Station : Put Panel 1.00 2017/5/23 Operation Name : Ver. : Date Glove Requirements: Half-finger gloves Steps： 1. Put Panel into the material box carefully. Note: If finding anything uncommon, notice foreman or assistant at once. Qty.
