Penberthy SErIES N6 GaGEcockS
InstallatIon, operatIon and maIntenance InstructIons
table 2 - tubular glass - ratIngs
⅝" (16 mm) and ¾" (19 mm) Od
Vessel tappings Ctr. to Ctr.
distance In
nPs dn
10 (254)
15 (381)
20 (508)
25 (635)
30 (762)
35 (889)
40 (1016)
45 (1143)
50 (1270)
55 (1397)
60 (1524)
65 (1651)
70 (1778)
N/a - Not available

2.3 application data

note: for specific application data, within the
above ranges, the user should consult the
product proposal for the specific model and
size gagecock set, or should request the supply
of the applicable technical data sheet.
WarnIng
Under no circumstances should these design
ratings or application data be exceeded.
Exceeding design ratings or application data may
cause severe physical injury or property damage.
3 InsPeCtIOn and PerfOrManCe
COnfIrMatIOn

3.1 receiving inspection

on receipt of gagecock set, check all
components carefully for damage incurred in
shipping. If damage is evident or suspected,
do not attempt installation. Notify the carrier
immediately and request a damage inspection.
up to 150° f (66°C)
high pressure heavy wall
psig (mPa) psig (mPa)
410 (2.83) 600 (4.14)
385 (2.65) 600 (4.14)
355 (2.45) 600 (4.14)
300 (2.07) 580 (4.00)
275 (1.90) 550 (3.80)
240 (1.65) 500 (3.45)
210 (1.45) 420 (2.90)
200 (1.38) 360 (2.48)
180 (1.24) 340 (2.34)
150 (1.03) N/a
140 (0.97) N/a
125 (0.86) N/a
100 (0.69) N/a

3.2 user's rating inspection

The user should confirm that:
1. The gagecock set model number and
pressure/temperature rating stamped on
nameplate (163) conforms to the description
on the user's purchase order.
2. The operating conditions described in
the purchase order agree with the actual
operating conditions at the installation site.
3. The actual operating conditions at the
installation site are within the application
data shown on the applicable technical
data sheet or product proposal referred to
previously.
4. The materials of construction of the
gagecocks are compatible with both
the contained fluid and the surrounding
atmosphere in the specific application.
safety InstruCtIOns
If the size, model or performance data of the
gagecock set as received does not conform with
any of the criteria above, do not proceed with
installation. Contact an authorized Penberthy
distributor for direction.
from 150° f (66°C) thru 400° f (204°C)
red line high pressure
psig (mPa) psig (mPa)
340 (2.34) 310 (2.14)
310 (2.14) 280 (1.97)
285 (1.97) 265 (1.83)
260 (1.79) 250 (1.72)
230 (1.59)
200 (1.38)
180 (1.24)
170 (1.17)
160 (1.10)
140 (0.97)
120 (0.83)
100 (0.69)
90 (0.62)
heavy wall red line
psig (mPa) psig (mPa)
345 (2.38) 275 (1.90)
325 (2.24) 265 (1.83)
315 (2.17) 260 (1.79)
300 (2.07) 250 (1.72)
