Product End-of-Life Disassembly Instructions
Product Category: Personal Computers
Marketing Name / Model
[List multiple models if applicable.]
HP EliteDesk 480 G4 Microtower Business PC
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions
for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU
directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
1.0 Items Requiring Selective Treatment
1.1 Items listed below are classified as requiring selective treatment.
1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as
applicable.
Item Description
Printed Circuit Boards (PCB) or Printed Circuit
Assemblies (PCA)
Batteries
Mercury-containing components
Liquid Crystal Displays (LCD) with a surface greater
than 100 sq cm
Cathode Ray Tubes (CRT)
Capacitors / condensers (Containing PCB/PCT)
Electrolytic Capacitors / Condensers measuring
greater than 2.5 cm in diameter or height
External electrical cables and cords
Gas Discharge Lamps
Plastics containing Brominated Flame Retardants
weighing > 25 grams (not including PCBs or PCAs
already listed as a separate item above)
Components and parts containing toner and ink,
EL-MF877-00
Template Revision B
Notes
With a surface greater than 10 sq cm
All types including standard alkaline and lithium coin
or button style batteries
For example, mercury in lamps, display backlights,
scanner lamps, switches, batteries
Includes background illuminated displays with gas
discharge lamps
Acbel EPA85
Include the cartridges, print heads, tubes, vent
PSG instructions for this template are available at
EL-MF877-01
Quantity
of items
included
in product
2
1
3
1
Page 1
Advertisement
Related Manuals for HP EliteDesk 480 G4
Summary of Contents for HP EliteDesk 480 G4
- Page 1 Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
- Page 2 including liquids, semi-liquids (gel/paste) and toner chambers, and service stations. Components and waste containing asbestos Components, parts and materials containing refractory ceramic fibers Components, parts and materials containing radioactive substances 2.0 Tools Required List the type and size of the tools that would typically be used to disassemble the product to a point where components and materials requiring selective treatment can be removed.
- Page 3 Figure 1 Loose thumb screw and remove access panel Figure 2 Disconnect ODD power cable from ODD Figure 3 Disconnect SATA cable from ODD Figure 4 Disconnect HDD Power cable from HDD Figure 5 Disconnect SATA cable from HDD Figure 6 Remove the driver cage from chassis EL-MF877-00 Page 3 Template Revision B...
- Page 4 Figure 7 Press the ODD’s latch on ODD cage Figure 8 Remove the ODD from ODD cage Figure 9 Use T-15 screwdriver to loose the screws of HDD Figure 10 Remove the HDD from HDD cage from cage Figure 11 Disconnect SATA cable from the MB Figure 12 Disconnect ODD/HDD PSU cables from the MB EL-MF877-00 Page 4...
- Page 5 Figure 13 Disconnect PSU P1 cable from the MB Figure 14 Disconnect PSU P2 cable from the MB Figure 15 Disconnect CPU P3 cable from the MB Figure 16 Disconnect Speaker cable from the MB Figure 17 Disconnect system fan cable from the MB Figure 18 Disconnect heat sink fan cable from MB EL-MF877-00 Page 5...
- Page 6 Figure 19 Use T-15 screwdriver to loose the screws and Figure 20 Use PH1 screwdriver to loose the screws and remove heat sink remove the fan Figure 21 Separate the fan from CPU heat sink Figure 22 Remove the Memory card from the board Figure 23 Rotate the handle and open it up Figure 24 Remove the CPU from the board EL-MF877-00...
- Page 7 Figure 25 Remove the battery from the system board Figure 26 Use T-15 screwdriver to loose the screws of MB from board Figure 27 Remove front panel from chassis Figure 28 Remove MB from chassis Figure 29 Use T-15 screwdriver to loose the screws of Figure 30 Use PH1 screwdriver to loose the screws of speaker and remove it system fan and remove it...
- Page 8 Figure 31 Use 170II micro shear to cut the cable ties from Figure 32 Use T-15 screwdriver to loose the screws of PSU chassis front wall Figure 33 Press the PSU’s latch on chassis Figure 34 Remove the PSU from chassis Figure 35 Use PH1 screwdriver to loose screws from top Figure 36 Use PH1 screwdriver to loose screws from bottom of PSU...
- Page 9 Figure 37 Use PH1 screwdriver to l oose screws of PSU fan Figure 38 Open the PSU case Figure 39 Use PH1 screwdriver to loose the screw of Figure 40 Use PH1 screwdriver to l oose screws and remove PCBA cable PCB from case Figure 41 Remove caps from PCB.
