OPERATOR'S MANUAL
CAUTION
BEFORE INSTALLING AND
USING THIS AIR CONDITIONER,
IT IS IMPORTANT THAT THIS
MANUAL BE READ AND
UNDERSTOOD THOROUGHLY
900-039-34 (2/19)
(CDR: 20131)
Keep This Manual
With Air Conditioner
AIR CONDITIONER
ADVANTAGE
RP52 SERIES
Find additional information on
this model at kooltronic.com or
use the Technical Documents
QR code below.
Technical
Documents
KOOLTRONIC, INC.
30 Pennington-Hopewell Road
Pennington, NJ 08534
609 • 466-3400
FAX: 609 • 466-1114
www.kooltronic.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Advantage RP52 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Kooltronic Advantage RP52 Series

Summary of Contents for Kooltronic Advantage RP52 Series

  • Page 1 ADVANTAGE RP52 SERIES Find additional information on this model at kooltronic.com or use the Technical Documents QR code below. Keep This Manual Technical With Air Conditioner Documents AIR CONDITIONER OPERATOR'S MANUAL CAUTION KOOLTRONIC, INC. 30 Pennington-Hopewell Road BEFORE INSTALLING AND...

  • Page 2: Table Of Contents

    Warranty I. Introduction Kooltronic Air Conditioners are designed to provide a cool, dehumidified environment for your electronic components. There are models to fit virtually all sizes and shapes of electronic enclosures, in capacities ranging from 1,000 to 30,000 BTU/H. Our "closed-loop" design also ensures that your components will not be exposed to hot, dirty operating conditions.

  • Page 3: Incoming Inspection

    Manual. See section VI PRE-INSTALLATION TESTING. 2) Before operating the Kooltronic Air Conditioner be certain that it is placed in its correct mounting position. All Air Conditioners containing an MM, NM, P, or V as part of the model number are designed to operate in a vertical position only.

  • Page 4: Product Identification Label

    IV. Product Identification and Nameplate Each Kooltronic Air Conditioner includes an identification nameplate. This nameplate provides: Model Number Serial Number Electrical power characteristics Maximum and minimum ambient operating temperatures Cooling capacity Type and amount of refrigerant required for recharging Design Pressure...

  • Page 5: Principles Of Operation

    AIR INLET (Ambient Air In) Kooltronic Air Conditioners are required when the equipment operating temperature must be kept near or lower than the ambient room temperature, and/or the cabinet must be sealed from dust, fumes, oil, corrosives and other contaminants. This Air Conditioner utilizes a "Closed-Loop Cooling System"...

  • Page 6: Pre-Installation Testing

    This is considered the maximum temperature within the enclosure and not the temperature of the air supplied to the enclosure. When the Kooltronic Air Conditioner is properly sized it should operate constantly and maintain 75ºF to 115ºF enclosure temperatures, depending on ambient temperatures.

  • Page 7: Specific Model Data

    [31.5] Dimensions (inches) are for reference only and are subject to change. Kooltronic Air Conditioners have been engineered to be installed easily. To avoid damaging your Air Conditioner, please read the following information before installation: 1. Loosen two screws on the bottom of the unit.

  • Page 8: Drawings And Dimensions

    Drawings and Dimensions...

  • Page 9: Technical Data

    Evaporator Blower Assembly 200052-00-59 Condenser Coil 0280-10 Evaporator Coil 0280-10 Filter 11751F NOTE: Part Numbers shown are for 60Hz/1Ø. For 50Hz consult Kooltronic. Standard Features Built-in Condensate Evaporator Low-ODP Referigerant EMI/RFI Suppressor Low Temperature Control Thermostat M/TAB Mounting System NEMA 3R Rating...

  • Page 10: Wiring Schematics

    Wiring Schematic EVAPORATOR BLOWER MOTOR CAP. SUPPRESSOR TRANSFORMER WITH TEMP. DISPLAY CRANKCASE HEATER THERMAL T-STAT HEATER CUT OUT OPTIONAL HEATER HEATER OPTIONAL SHORT CYCLE SHORT PROTECTOR CYCLE TIMER T-STAT RELAY SET 75°F COIL PRESSURE SWITCH N.O. CONDENSER BLOWER CAP. MOTOR COOLING EFFECT DETECTOR COMPRESSOR TO CUSTOMER...

  • Page 11: Maintenance

    5) The filters may be sprayed with Kooltronic A-16 Filter Recoating Adhesive to trap fine airborne contaminants, or they may simply be dried and reinstalled as strainer type filters.
  • Page 12 Refer to the data on the unit name plate which specifies the type of refrigerant and the amount of charge in ounces. E. Relocation If your Kooltronic Air Conditioner has to be moved to another location by truck, the following precautions should be taken: De-mount Air Conditioner from equipment, controller or enclosure.

  • Page 13: Trouble Shooting

    IX. Trouble-Shooting Each Kooltronic Air Conditioner is engineered for performance and built for reliability. They are designed to require no routine maintenance other than the cleaning of ambient air filters. If your air conditioner should require service, we have compiled a trouble-shooting chart to assist your service personnel.

  • Page 14: Warranty

    THIS WARRANTY CONSTITUTES THE ENTIRE WARRANTY WITH RESPECT TO THE PRODUCT AND IS IN LIEU OF ALL OTHERS, EXPRESSED OR IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY AND WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE AND IN NO EVENT IS KOOLTRONIC RESPONSIBLE FOR ANY CONSEQUENTIAL DAMAGES OF ANY NATURE WHATSOEVER.
