Teletronics International TT5800 Quick User Manual

Package Contains

1. TT5800 802.11a PCBA (1)
2. IEEE 802.11a miniPCI radio card (1)
3. Power over Ethernet Injector (1)
4. 48VDC Power Adapter (1)
5. Ethernet Cable (2)
6. Waterproof RJ-45 Connector (1)
7. Mounting Hardware (1)
8. 23dBi Subscriber antenna,
9. 20cm RF cable (cable loss: 8dB)
10. User Manual

Quick Installation

Always double check for any missing parts from the kit you received before deployment.
Next step is to set up the computer Ethernet interface for configuring the TT5800. Since the default IP Address of the
unit is on the 192.168.10.x IP range in both Client Bridge and AP mode you'll need to set the computer Ethernet
interface within the same IP range, such as 192.168.10.66.

Hardware Installation

Follow the procedure below to install your TT5800 device:
1. Select a suitable place on the network to install the TT5800. For best wireless reception and performance the
external antenna should be positioned within Line of Sight from the AP with proper alignment.
2. Connect the TT5800 to the ODU side of the PoE Injector via a straight Ethernet cable (Cat-5), then connect the
NET side of the PoE Injector to either a computer or an Ethernet Switch.
Note: The TT5800 now fully supports the MDI/MDI-X standard and no longer require the use of cross over cable to
connect directly with a computer.
3. Connect the 48VDC power adapter to the power jack on the PoE injector to power on the TT5800.
Check the LEDs on the TT5800 to confirm if the status is okay. At this point the PWR and LAN LEDs should be on
green. The WLAN light should light up once the unit is associated wirelessly with another wireless device. However
at this point the unit is still in factory default setting so do not the alarmed that the WLAN light doesn't light up.
TT5800 Quick User Guide
802.11a 310mW
